939 Convoluted PTFE Hose
939, 939B
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating Weight
Crimp
Fitting
83C
Crimp
Die
hose
inch mm inch mm wpsi
MPa inch mm inch/Hg.
lbs/ft
kg/m series
pg
crimp die
939-6
3/8
10 0.59 15 1500 10 2.25
57
28
.12
17.9
93
165-168
939-8
1/2 12.5 0.79 20 1350 9
2.88
73
28
.211
31.4
93N 165-168
T08
939-10
5/8
16 0.88 22 1000 7
3.00
76
28
.24
35.7
93N 165-168
T10
939-12
3/4
19 1.09 28 1100 8
3.75
95
28
.316
47.0
93N 165-168
T12
939-16
1
25 1.33 34 1000 7
5.00 127
28
.451
67.1
93N 165-168
T16
939-20
1-1/4 31.5 1.75 44 1000 7
6.25 159
20*
.697 103.7 93N 165-168
T20
939-24
1-1/2 38 2.05 52 750 5
7.50 191
12*
.795 118.3 93N 165-168
T24
939-32
2
51 2.56 57 250 2 10.00 254
5*
1.01 150.3 93N 165-168
T32
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating
Weight
Crimp
Fitting
83C
Crimp
Die
hose
inch mm inch mm wpsi
MPa inch mm inch/Hg.
lbs/ft
kg/m series
pg
crimp die
939B-6
3/8
10 0.59
15 1500 10 2.25 57
28
.12
17.9
93
165-168
939B-8
1/2 12.5 0.79
20 1350 9
2.88 73
28
.211
31.4
93N 165-168
T08
939B-10
5/8
16 0.88
22 1000 7
3.00 76
28
.24
35.7
93N 165-168
T10
939B-12
3/4
19 1.09
28 1100 8
3.75 95
28
.316
47.0
93N 165-168
T12
939B-16
1
25 1.33
34 1000 7
5.00 127
28
.451
67.1
93N 165-168
T16
939B-20
1-1/4 31.5 1.75
44 1000 7
6.25 159
20*
.697 103.7 93N 165-168
T20
939B-24
1-1/2 38 2.05
52 750 5
7.50 191
12*
.795 118.3 93N 165-168
T24
939B-32
2
51 2.56
57 250 2 10.00 254
5*
1.01 150.3 93N 165-168
T32
939B Convoluted PTFE Hose
Tube:
Natural FDA Compliant PTFE
Reinforcement:
304 Stainless Steel
Temperature:
-100°F to +450°F
-73°C to +232°C
Not recommended for steam-cold water cycling applications.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Transfer lines for nearly all chemicals • Compressed Air/Gases
*Use hose type 939B with static-dissipative core tube when
conveying non-conducting fluids such as oils, paints, fuels, steam, etc.
Special Features:
• Better flexibility
• Exceptional kink resistance
Tube:
Black Static-Dissipative PTFE
Reinforcement:
304 Stainless Steel
Temperature:
-100°F to +450°F
-73°C to +232°C
Not recommended for steam-cold water cycling applications.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Transfer lines for nearly all chemicals • Hot oils
• Compressed Air/Gases
Special Features:
• Better flexibility
• Exceptional kink resistance
Note:
A non-standard version of this hose is available with blue polyester braid instead of stainless steel reinforcement. Contact Parflex
for performance specifications and availability.
