929, 929B
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating Weight
Crimp
Fitting
80C
Crimp
Die
hose inch mm inch mm inch wpsi MPa inch mm inch/Hg. lbs/ft kg/m series pg crimp die
929-4 3/16 5 5/16 8 .040 3000 21 1.5 38 28 .8 11.9 91N 150-164 T04N
929-6 5/16 8 7/16 11 .040 2500 17 3.5 89 28 .121 18.0 91N 150-164 T06N
929-8 13/32 10 9/16 14 .042 2000 14 4.5 114 28 .157 23.3 91N 150-164 T08N
929-12 (+) 5/8 16 3/4 19 .048 1200 8 6.5 165 12 .186 27.7 91N 150-164 T12N
929B Heavy Wall PTFE Hose with Static-Dissipative Tube
Exceeds SAE 100R14B Performance
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating Weight
Crimp
Fitting
80C
Crimp
Die
hose inch mm inch mm inch wpsi MPa inch mm inch/Hg. lbs/ft kg/m series pg crimp die
929B-4 3/16 5 5/16 8 .040 3000 21 1.5 38 28 .8 11.9 91N 150-164 T04N
929B-6 5/16 8 7/16 11 .040 2500 17 3.5 89 28 .121 18.0 91N 150-164 T06N
929B-8 13/32 10 9/16 14 .042 2000 14 4.5 114 28 .157 23.3 91N 150-164 T08N
929B-12 5/8 16 3/4 19 .048 1200 8 6.5 165 12 .186 27.7 91N 150-164 T12N
929B-16 7/8 22 1-1/8 29 .048 1250 9 7.4 188 14 .488 72.6 91N 150-164 T16H
929 Heavy Wall PTFE Hose
Exceeds SAE 100R14A Performance
Tube: Natural FDA Compliant PTFE
Reinforcement: 304 Stainless Steel
Temperature: -100°F to +450°F
-73°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Instrumentation Lines
• Sampling/Analyzing Lines
• 919 applications requiring tight routing
*Use hose type 929B with static-dissipative core tube when
conveying non-conducting fluids such as oils, paints, fuels,
steam, etc.
Special Features:
• Tighter bend radius
• Better kink resistance
• Enhanced resistance to gas permeation
Tube: Black Static-Dissipative PTFE
Reinforcement: 304 Stainless Steel
Temperature: -100°F to +450°F
-73°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• 919B applications requiring tight routing or enhanced
permeation resistance
Special Features:
• Tighter bend radius
• Better kink resistance
• Enhanced resistance to gas permeation
