919, 919B
919 PTFE Hose
Exceeds SAE 100R14A
(+) Non Standard. See page ii for information on non-standard products.
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vac.
Rating Weight
Crimp
Fitting
80C
Crimp
Die
Field
Attachable
Fitting
hose inch mm inch mm inch wpsi MPa inch mm inch/Hg. lbs/ft kg/m series pg crimp die re pg
919-3 (+) 1/8 3 1/4 6 .030 3000 20.7 1.5 38 28 .038 5.7 91 150-164 T03
919-4 3/16 5 5/16 8 .030 3000 20.7 2.0 51 28 .059 8.9 91N 150-164 T04N 90 142-149
919-5 1/4 6 3/8 10 .030 3000 20.7 3.0 76 28 .086 12.7 91N 150-164 T05N 90 142-149
919-6 5/16 8 7/16 11 .030 2500 17.2 4.0 102 28 .103 15.3 91N 150-164 T06N 90 142-149
919-8 13/32 10.5 17/32 14 .030 2000 13.8 5.0 127 28 .126 18.8 91N 150-164 T08N 90 142-149
919-10 1/2 12.5 5/8 16 .030 1500 10.3 6.5 165 28 .149 22.1 91N 150-164 T10N 90 142-149
919-12 5/8 16 3/4 19 .030 1200 8.3 7.5 191 12 .186 27.7 91N 150-164 T12N 90 142-149
919-16 7/8 22 1-1/32 26 .035 1000 6.9 9.0 229 14 .268 39.9 91N 150-164 T16N 90 142-149
919-20 1-1/8 29 1-9/32 33 .042 625 4.3 16.0 406 10 .388 57.7 91 150-164 T20 90 142-149
Tube: Natural FDA Compliant PTFE
Reinforcement: 304 Stainless Steel
Temperature: -100°F to +450°F
-73°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Transfer lines for nearly all chemicals • Hot oils
• Compressed Air/Gases • Adhesive dispensing
• Coolant Lines • Medical Gases
*Use hose type 919B with static-dissipative core tube when conveying
non-conducting fluids such as oils, paints, fuels, steam, etc..
919B PTFE Hose with Static-Dissipative Tube
Exceeds SAE 100R14B
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vac.
Rating Weight
Crimp
Fitting
80C
Crimp
Die
Field
Attachable
Fitting
hose inch mm inch mm inch wpsi MPa inch mm inch/Hg. lbs/ft kg/m series pg crimp die re pg
919B-5 1/4 6 3/8 10 .030 3000 20.7 3.0 76 28 .086 12.7 91N 150-164 T05N 90 142-149
919B-6 5/16 8 7/16 11 .030 2500 17.2 4.0 102 28 .103 15.3 91N 150-164 T06N 90 142-149
919B-8 13/32 10 17/32 14 .030 2000 13.8 5.0 127 28 .126 18.8 91N 150-164 T08N 90 142-149
Tube: Black Static-Dissipative PTFE
Reinforcement: 304 Stainless Steel
Temperature: -100°F to +450°F
-73°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Transfer lines for nearly all chemicals • Hot oils
• Compressed Air/Gases • Fuel Lines
• Adhesive dispensing • Coolant Lines
• Paints/Coatings • Steam Transfer
