919J Silicone Jacketed PTFE Hose
Exceeds SAE 100R14A Performance
919J
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating Weight
Crimp
Fitting
80C
Crimp
Die
hose inch mm inch mm inch wpsi MPa inch mm inch/Hg. lbs/ft kg/m series pg crimp die
919J-4-RED 3/16 5 0.45 11 .030 3000 21 2.0 51 28 .124 18.4 91N 150-164 T04J
919J-5-RED (+) 1/4 6.3 0.52 13 .030 3000 21 3.0 76 28 .142 21.1 91N 150-164 T05J
919J-6-RED 5/16 8 0.58 15 .030 2500 17 4.0 102 28 .165 24.5 91N 150-164 T06J
919J-8-RED 13/32 10 0.68 17 .030 2000 14 5.0 127 28 .202 30.3 91N 150-164 T08J
919J-10-RED 1/2 12.5 0.78 20 .030 1500 10 6.5 165 28 .236 35.2 91N 150-164 T10J
919J-12-RED 5/8 16 0.91 23 .030 1200 8 7.5 191 12 .291 43.2 91N 150-164 T12J
(+) Non Standard. See page ii for information on non-standard products.
Tube: Natural FDA Compliant PTFE
Reinforcement: 304 Stainless Steel
Cover: Red Extruded Silicone
Temperature: -40°F to +450°F
-40°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Transfer lines for nearly all chemicals • Coolant Lines
• Compressed Air/Gases • Adhesive dispensing
Special Features:
• Silicone jacket protects stainless steel wire reinforcement
against wear and fraying even at temperatures up to 450F.
• Silicone jacket provides clean smooth cover and prevents
contaminants from accumulating in braided reinforcement.
• Steam Cleanable
• Other non-standard colors available, including white FDA
compliant silicone.
• Cover must be skived prior to fitting attachment
