22 www.oetiker.com Rights to make technical changes in the interests of further development reserved 08901456
®
Features
• Separate locks (screw or ratchet) with perforated band steel
• Universally applicable at various diameters and widths
• Supplied in kit format, bulk, or to customer specification
• With ratchet lock, installation and removal is possible without tools
• Reusable
For detailed information, please request the Technical Data Sheet for this OETIKER
product group. Send your sample parts and all relevant information for your specific
application to OETIKER, and you will receive our recommendation for product type,
diameter, and method of installation.
The combination of OETIKER ratchet or screw locks with perforated
stainless steel band strip is part of the OETIKER Universal Clamp
Program, and can be used for diameters greater than 35 mm.
The versatility of OETIKER Universal Clamps are second to none
as they can be used as an alternative to most OETIKER Clamps, in
maintenance, repair, and aftermarket purposes.
When the ratchet lock is employed, the clamp can even be installed
and removed without tools.
Universal clamps are suitable for unpressurized retaining functions,
e.g. for filters, dust bags, or induction hoses.
Material
– 174 All parts are Stainless Steel,
Material no. 1.4301 / UNS S30400
Size range Width x Thickness
= 35.0 mm 10.0 x 0.5 mm
= 80.0 mm 18.0 x 0.8 mm*
Installation
Installation instructions available on request.
* For use with 18 mm screw lock
OETIKER
Universal Clamps
Product Group 174
Screw Lock 18 mm
Screw Lock 10 mm
