General Purpose
9 We recommend a minimum of all 300 grade stainless steel clamps for marine applications.
For applications directly over galvanized steel, we recommend an intermediate layer of non-conductive material such as vinyl electrical tape.
Clamping Range Fits Hose I.D.
Ideal Part No. Tridon Part No. Ideal Part No. Tridon Part No.
mm in. mm in.
Min. Dia. Max. Dia. Min. Dia. Max. Dia. Min. Dia. Max. Dia. Min. Dia. Max. Dia.
53101 0012 901-0012 53103 0012 903-0012 8 12 5/16 15/32 - 5 1/8 3/16
53101 0016 901-0016 53103 0016 903-0016 10 16 13/32 5/8 6 7 1/4 3/8
53101 0020 901-0020 53103 0020 903-0020 12 20 1/2 25/32 7 10 5/16 1/2
53101 0025 901-0025 53103 0025 903-0025 16 25 21/32 31/32 9 16 1/2 5/8
53101 0032 901-0032 53103 0032 903-0032 20 32 25/32 1 1/4 13 22 5/8 7/8
53101 0040 901-0040 53103 0040 903-0040 25 40 1 1 9/16 19 29 3/4 1
W2 53101 0050 901-0050 W4 53103 0050 903-0050 32 50 1 1/4 1 31/32 25 38 1 1 3/8
53101 0060 901-0060 53103 0060 903-0060 40 60 1 19/32 2 11/32 32 44 1 1/4 1 3/4
53101 0070 901-0070 53103 0070 903-0070 50 70 1 31/32 2 3/4 41 57 1 5/8 2
53101 0080 901-0080 53103 0080 903-0080 60 80 2 3/8 3 1/8 51 64 2 2 1/2
53101 0090 901-0090 53103 0090 903-0090 70 90 2 3/4 3 1/2 64 76 2 1/2 3
53101 0100 901-0100 53103 0100 903-0100 80 100 3 1/8 3 15/16 76 83 3 3 1/2
53101 0110 901-0110 53103 0110 903-0110 90 110 3 9/16 4 5/16 83 89 3 1/4 3 3/4
53101 0120 901-0120 53103 0120 903-0120 100 120 3 15/16 4 23/32 89 102 3 1/2 4
53101 0130 901-0130 53103 0130 903-0130 110 130 4 5/16 5 1/8 102 114 4 4 1/2
Clamping Range Fits Hose I.D.
Ideal Part No. Tridon Part No. Ideal Part No. Tridon Part No.
mm in. mm in.
Min. Dia. Max. Dia. Min. Dia. Max. Dia. Min. Dia. Max. Dia. Min. Dia. Max. Dia.
53102 0025 902-0025 53104 0025 904-0025 16 25 21/32 31/32 9 16 1/2 5/8
53102 0032 902-0032 53104 0032 904-0032 20 32 25/32 1 1/4 13 22 5/8 7/8
53102 0040 902-0040 53104 0040 904-0040 25 40 1 1 9/16 19 29 3/4 1
53102 0050 902-0050 53104 0050 904-0050 32 50 1 1/4 1 31/32 25 38 1 1 3/8
53102 0060 902-0060 53104 0060 904-0060 40 60 1 19/32 2 11/32 32 44 1 1/4 1 3/4
W2 53102 0070 902-0070 W4 53104 0070 904-0070 50 70 1 31/32 2 3/4 41 57 1 5/8 2
53102 0080 902-0080 53104 0080 904-0080 60 80 2 3/8 3 1/8 51 64 2 2 1/2
53102 0090 902-0090 53104 0090 904-0090 70 90 2 3/4 3 1/2 64 76 2 1/2 3
53102 0100 902-0100 53104 0100 904-0100 80 100 3 1/8 3 15/16 76 83 3 3 1/2
53102 0110 902-0110 53104 0110 904-0110 90 110 3 9/16 4 5/16 83 89 3 1/4 3 3/4
53102 0120 902-0120 53104 0120 904-0120 100 120 3 15/16 4 23/32 89 102 3 1/2 4
53102 0130 902-0130 53104 0130 904-0130 110 130 4 5/16 5 1/8 102 114 4 4 1/2
53102 902 53104 904
53101 901 53103 903
12mm BAND WIDTH NON-PERFORATED (EMBOSSED) CLAMPS
9mm BAND WIDTH NON-PERFORATED (EMBOSSED) CLAMPS
