Heavy-Duty
We offer one of the most comprehensive lines of heavy-duty clamping products in the business. Our heavy-duty products
include T-Bolts, Spring Loaded T-Bolts, V-Bands, Heavy-Duty and Constant Tension worm drive clamps. We cover the world
of heavy-duty truck, off-road and industrial applications. We can even custom engineer a product that will meet your special
fastening requirements.
Channel Bridge T-Bolts – Ideal 30020 Series/ Tridon 814 Series
Channel bridge T-Bolts provide the added insurance of a rigid bridge liner to help
prevent leak paths in more demanding applications. Typical applications include truck
air intake systems, cold side charge air systems and industrial equipment and machinery.
Band/Bridge: 3/4" width, 201/301 stainless steel.
Bolt: 1/4"-28 plated steel.
Nut: 7/16" hex, nylon insert, plated steel locknut.
Trunnion: Plated steel.
Covers clamping ranges from 1 3/8" to 8 1/2".
Additional clamping ranges and designs are
available on request – Contact Ideal for information.
Standard T-Bolts – Ideal 30010 Series/ Tridon 813 Series
The most widely used T-Bolt clamp design. Typical applications include truck air intake
systems, cold side charge air systems, off-road equipment and industrial machinery.
Band/Liner: 3/4" width, 201/301 stainless steel.
Bolt: 1/4"-28, plated steel.
Nut: 7/16" hex, nylon insert, plated steel locknut.
Trunnion: Plated steel.
Covers clamping ranges from 1 3/8" to 8 1/2".
Additional clamping ranges and designs are
available on request – Contact Ideal for information.
T-BOLTS
Heavy-duty T-Bolt clamps provide uniform sealing pressure for a positive, reliable seal. Specifically designed for use in the high
vibration and large diameter applications common in heavy truck, off-road equipment and industrial machinery, our T-Bolts
feature a 3/4" wide stainless steel band and welded construction for reliability. They are available in part or all stainless steel
construction and in Standard T-Bolt, Channel Bridge T-Bolt and Spring Loaded T-Bolt designs.
Spring Loaded T-Bolts – Ideal 30030 Series / Tridon 819 Series
The helical spring design provides the self-compensating (constant tension) feature
that prevents the development of leak paths due to temperature fluctuations. Typical
applications include heavy truck charge air and cooling systems.
Band/Bridge: 3/4" width, 201/301 stainless steel.
Bolt: 1/4"-28 plated steel. Spring: Plated steel.
Nut: 7/16" hex, nylon insert, plated steel locknut.
Trunnion: Plated steel.
Covers clamping ranges from 3 1/16" to 4 9/16".
Additional clamping ranges and designs are
available on request – Contact Ideal for information.
For applications involving both high temperatures and the presence of chlorides, or any other special applications, contact us.
We will be glad to help solve your particular fastening problem. Our toll free Help Line is 1-800-221-0100. Ask for Clamp Product Engineering. 10
