Heavy-Duty
V-BANDS
V-Bands provide a secure, reliable connection for virtually any flanged joint.
Typical applications include filter housings, turbocharger systems, exhaust systems
and industrial applications where a flanged connection is required.
V-Bands are available in a wide range of band and v-insert configurations.
Contact Ideal with your special requirements.
SPRING LOADED T-BOLTS
SAE Spring Loaded T-Bolt
Sizes Ideal Tridon
Part No. Part No.
70 30030 0306 819-306 3 1/16 3 3/8 77.8 85.7 75.0 in. lbs. (8.5 Nm)
86 30030 0356 819-356 3 9/16 3 7/8 90.5 98.4 75.0 in. lbs. (8.5 Nm)
102 30030 0406 819-406 4 1/16 4 3/8 103.2 111.1 75.0 in. lbs. (8.5 Nm)
118 30030 0456 819-456 4 9/16 4 7/8 115.9 123.8 75.0 in. lbs. (8.5 Nm)
Additional sizes and designs available – Contact Ideal for information.
Min. Dia. Max. Dia. Min. Dia. Max. Dia. Installation
(Inches) (Inches) (mm) (mm) Torque
Min. Dia. Max. Dia. Min. Dia. Max. Dia. Installation
(Inches) (Inches) (mm) (mm) Torque
STANDARD AND CHANNEL BRIDGE T-BOLTS
SAE Standard T-Bolt Channel Bridge T-Bolt
Sizes Ideal Tridon Ideal Tridon
Part No. Part No. Part No. Part No.
– 30010 0138 813-138 30020 0138 814-138 1 3/8 1 9/16 35.1 38.6 75.0 in. lbs. (8.5 Nm)
– 30010 0150 813-150 30020 0150 814-150 1 1/2 1 5/8 38.1 41.7 75.0 in. lbs. (8.5 Nm)
– 30010 0163 813-163 30020 0163 814-163 1 5/8 1 7/8 41.4 46.0 75.0 in. lbs. (8.5 Nm)
28 30010 0175 813-175 30020 0175 814-175 1 3/4 2 44.5 50.8 75.0 in. lbs. (8.5 Nm)
32 30010 0188 813-188 30020 0188 814-188 1 7/8 2 3/16 47.8 55.6 75.0 in. lbs. (8.5 Nm)
36 30010 0200 813-200 30020 0200 814-200 2 2 5/16 50.8 58.7 75.0 in. lbs. (8.5 Nm)
40 30010 0213 813-213 30020 0213 814-213 2 1/8 2 7/16 54.1 62.0 75.0 in. lbs. (8.5 Nm)
44 30010 0225 813-225 30020 0225 814-225 2 1/4 2 9/16 57.2 65.0 75.0 in. lbs. (8.5 Nm)
48 30010 0238 813-238 30020 0238 814-238 2 3/8 2 11/16 60.5 68.3 75.0 in. lbs. (8.5 Nm)
52 30010 0250 813-250 30020 0250 814-250 2 1/2 2 13/16 63.5 71.4 75.0 in. lbs. (8.5 Nm)
56 30010 0263 813-263 30020 0263 814-263 2 5/8 2 15/16 66.8 74.7 75.0 in. lbs. (8.5 Nm)
60 30010 0275 813-275 30020 0275 814-275 2 3/4 3 1/16 69.9 77.7 75.0 in. lbs. (8.5 Nm)
64 30010 0288 813-288 30020 0288 814-288 2 7/8 3 3/16 73.2 81.0 75.0 in. lbs. (8.5 Nm)
68 30010 0300 813-300 30020 0300 814-300 3 3 5/16 76.2 84.1 75.0 in. lbs. (8.5 Nm)
72 30010 0313 813-313 30020 0313 814-313 3 1/8 3 7/16 79.5 87.4 75.0 in. lbs. (8.5 Nm)
76 30010 0325 813-325 30020 0325 814-325 3 1/4 3 9/16 82.6 90.4 75.0 in. lbs. (8.5 Nm)
80 30010 0338 813-338 30020 0338 814-338 3 3/8 3 11/16 85.9 93.7 75.0 in. lbs. (8.5 Nm)
84 30010 0350 813-350 30020 0350 814-350 3 1/2 3 13/16 88.9 96.8 75.0 in. lbs. (8.5 Nm)
88 30010 0363 813-363 30020 0363 814-363 3 5/8 3 15/16 92.2 100.1 75.0 in. lbs. (8.5 Nm)
92 30010 0375 813-375 30020 0375 814-375 3 3/4 4 1/16 95.3 103.1 75.0 in. lbs. (8.5 Nm)
100 30010 0400 813-400 30020 0400 814-400 4 4 5/16 101.6 109.5 75.0 in. lbs. (8.5 Nm)
108 30010 0425 813-425 30020 0425 814-425 4 1/4 4 9/16 108.0 115.8 75.0 in. lbs. (8.5 Nm)
116 30010 0450 813-450 30020 0450 814-450 4 1/2 4 13/16 114.3 122.2 75.0 in. lbs. (8.5 Nm)
124 30010 0475 813-475 30020 0475 814-475 4 3/4 5 1/16 120.7 128.5 75.0 in. lbs. (8.5 Nm)
132 30010 0500 813-500 30020 0500 814-500 5 5 5/16 127.0 134.9 75.0 in. lbs. (8.5 Nm)
140 30010 0525 813-525 30020 0525 814-525 5 1/4 5 9/16 133.4 141.2 75.0 in. lbs. (8.5 Nm)
148 30010 0550 813-550 30020 0550 814-550 5 1/2 5 13/16 139.7 147.6 75.0 in. lbs. (8.5 Nm)
156 30010 0575 813-575 30020 0575 814-575 5 3/4 6 1/16 146.1 153.9 75.0 in. lbs. (8.5 Nm)
164 30010 0600 813-600 30020 0600 814-600 6 6 5/16 152.4 160.3 75.0 in. lbs. (8.5 Nm)
172 30010 0625 813-625 30020 0625 814-625 6 1/4 6 9/16 158.8 166.6 75.0 in. lbs. (8.5 Nm)
180 30010 0650 813-650 30020 0650 814-650 6 1/2 6 13/16 165.1 173.0 75.0 in. lbs. (8.5 Nm)
188 30010 0675 813-675 30020 0675 814-675 6 3/4 7 1/16 171.5 179.3 75.0 in. lbs. (8.5 Nm)
196 30010 0700 813-700 30020 0700 814-700 7 7 5/16 177.8 185.7 75.0 in. lbs. (8.5 Nm)
204 30010 0725 813-725 30020 0725 814-725 7 1/4 7 9/16 184.2 192.0 75.0 in. lbs. (8.5 Nm)
212 30010 0750 813-750 30020 0750 814-750 7 1/2 7 13/16 190.5 198.4 75.0 in. lbs. (8.5 Nm)
220 30010 0775 813-775 30020 0775 814-775 7 3/4 8 1/16 196.9 204.7 75.0 in. lbs. (8.5 Nm)
228 30010 0800 813-800 30020 0800 814-800 8 8 5/16 203.2 211.1 75.0 in. lbs. (8.5 Nm)
236 30010 0825 813-825 30020 0825 814-825 8 1/4 8 9/16 209.6 217.4 75.0 in. lbs. (8.5 Nm)
244 30010 0850 813-850 30020 0850 814-850 8 1/2 8 13/16 215.9 223.8 75.0 in. lbs. (8.5 Nm)
Additional sizes and designs available – Contact Ideal for information.
We recommend a minimum of all 300 grade stainless steel clamps for marine applications.
For applications directly over galvanized steel, we recommend an intermediate layer of non-conductive material such as vinyl electrical tape. 11
