Pressureflex is Hose Master’s high-pressure, annular corrugated metal hose. With all the
advantages of a hydroformed hose, Pressurefex is made from heavy-wall T321 stainless steel.
Pressurefex offers fexibility and dependability when higher pressures are a factor.
Example: AF8750 = T321 stainless steel, annular corrugated metal hose with a single T304 stainless steel braid
* 5 inch and 6 inch diameters are supplied with braided braid
** Pressurefex T321 hose is supplied only with T321 stainless steel braid in 2, 2-1/2, 3 & 4 inch sizes
+ Pressurefex T316L is only available in 3/4, 1, 1-1/4, 1-1/2, & 2 inch sizes, and is supplied with T304 stainless steel braid
• The minimum bend radius is measured from the centerline of the hose
• The working pressure decreases with temperature - obtain derating factor on page 33 in Technical Information
• For rapid pressure fuctuations, consult factory
Braid Codes
00 - Unbraided
50 - T304 Single Braid
55 - T304 Double Braid
70 - T321 Single Braid
77 - T321 Double Braid
Inside
Diameter
(in.)
Number of
Braids
(#)
Outside
Diameter
(in.)
Static
Minimum
Bend
Radius
(in.)
Dynamic
Minimum
Bend
Radius
(in.)
Maximum
Working
Pressure
(psi)
Burst
Pressure
(psi)
Weight
Per Foot
(lbs.)
3/4+
0
1
2
1.13
1.19
1.25
4.0 8.0
220
1100
1650
n/a
4430
6696
0.41
0.58
0.76
1+
0
1
2
1.43
1.49
1.55
5.0 9.0
190
1000
1400
n/a
4187
5837
0.52
0.76
0.99
1 1/4+
0
1
2
1.74
1.82
1.90
6.5 12.0
200
900
1350
n/a
3758
5494
0.76
1.13
1.50
1 1/2+
0
1
2
2.10
2.18
2.26
7.5 13.0
90
750
1200
n/a
3070
4842
1.13
1.54
1.96
2**+
0
1
2
2.55
2.68
2.80
9.0 15.0
105
800
1150
n/a
3304
4738
1.10
2.29
3.47
2 1/2**
0
1
2
3.35
3.48
3.60
10.5 17.0
46
575
900
n/a
2461
3857
1.75
2.55
3.35
3**
0
1
2
3.67
3.79
3.92
12.0 20.0
36
550
800
n/a
2252
3254
1.92
3.18
4.46
4**
0
1
2
4.92
5.04
5.16
9.8 25.0
28
330
495
n/a
1319
1979
2.80
4.27
5.74
5* 0
1
5.96
6.13 12.8 34.0 28
331
n/a
1324
3.03
5.14
6* 0
1
6.97
7.22 14.8 40.0 23
285
n/a
1140
3.74
6.44
Material Codes
8 - T321 Stainless Steel
9 - T316L Stainless Steel
Explanation of Pressurefex Part Numbers
AF _____ 7 ______HP
Material
Code
Braid
Code
