PressureMax HP® is Hose Master’s hydroformed annular, heavy-wall corrugated metal hose,
specifcally designed for ULTRA-high-pressure applications. PressureMax HP® offers superior
fexibility and is made from heavy-wall T321 stainless steel.
Braid Codes
00 - Unbraided
70 - T321 Single Braid
77 - T321 Double Braid
7T - T321 Triple Braid
7Q - T321 Quad Braid
Example: AF8570 = T321 stainless steel, annular corrugated metal hose with a single T321 stainless steel braid
• The minimum bend radius is measured from the centerline of the hose
• The working pressure decreases with temperature - obtain derating factor on page 33 in Technical Information
• For rapid pressure fuctuations, consult factory
Inside
Diameter
(in.)
Number of
Braids
(#)
Outside
Diameter
(in.)
Static
Minimum
Bend
Radius
(in.)
Dynamic
Minimum
Bend
Radius
(in.)
Maximum
Working
Pressure
(psi)
Burst
Pressure
(psi)
Weight
Per Foot
(lbs.)
3/4*
0
1
2
1.15
1.28
1.40
2.5
4.0
4.0
4.5
10.0
10.0
250
2650
3600
n/a
10669
14521
0.63
1.09
1.58
1*
0
1
2
1.45
1.57
1.70
3.25
5.0
5.0
7.0
11.0
11.0
180
2500
3000
n/a
10000
12083
0.84
1.53
2.25
1 1/4*
0
1
2
3
1.75
1.88
2.00
2.13
5.0
6.5
6.5
7.0
9.5
12.5
12.5
14.0
190
1775
2600
3000
n/a
7119
10400
12082
1.32
2.09
2.88
3.71
1 1/2*
0
1
2
2.11
2.23
2.36
6.0
7.5
7.5
11.5
13.0
13.0
110
1450
2200
n/a
5800
8892
1.75
2.64
3.57
2*
0
1
2
2.57
2.70
2.82
7.5
9.0
9.0
12.0
14.0
14.0
100
1100
1675
n/a
4415
6710
2.04
3.23
4.45
2 1/2
0
1
2
3.38
3.51
3.63
8.0
9.5
9.5
14.5
16.0
16.0
46
700
1050
n/a
2800
4200
2.73
4.03
5.33
3
0
1
2
3
3.70
3.83
3.95
4.08
8.5
10.5
10.5
23.0
16.0
20.0
20.0
75.0
36
600
900
1200
n/a
2400
3600
4800
3.13
4.39
5.67
6.99
4
0
1
2
4
4.82
4.94
5.07
5.32
10.0
13.0
13.0
32.0
19.0
26.0
26.0
96.0
23
525
875
1200
n/a
2100
3500
4800
5.11
6.94
8.80
12.62
Material Codes
8 - T321 Stainless Steel
9 - T316L Stainless Steel
Explanation of PressureMax HP® Part Numbers
AF _____ 5 ______HP
Material
Code
Braid
Code
* PressureMax HP® T316L hose is only available in 3/4, 1, 1 1/4, 1 1/2, & 2 inch diameters
