MASTERFLEX
Masterflex is manufactured using the same high quality process used to make Annufex hose,
but the number of corrugations per foot is increased to provide for greater fexibility.
Explanation of Masterfex Part Numbers
AF _______ 5 _______
Material Code Braid Code
Material Codes
4 - T321 Stainless Steel
5 - T316L Stainless Steel
7 - T304L Stainless Steel
Example: AF4550 = T321 stainless steel, annular corrugated metal hose with a single T304 stainless steel braid
• The minimum bend radius is measured from the centerline of the hose
• The working pressure decreases with temperature - obtain derating factor on page 33 in Technical Information
• For rapid pressure fuctuations, consult factory
Braid Codes
00 - Unbraided
50 - T304 Single Braid
55 - T304 Double Braid
T316 Braid available upon request
Inside
Diameter
(in.)
Number of
Braids
(#)
Outside
Diameter
(in.)
Static
Minimum
Bend
Radius
(in.)
Dynamic
Minimum
Bend
Radius
(in.)
Maximum
Working
Pressure
(psi)
Burst
Pressure
(psi)
Weight
Per Foot
(lbs.)
1/4
0
1
2
0.42
0.48
0.54
0.9 3.7
90
1800
2700
n/a
7233
9100
0.07
0.14
0.20
3/8
0
1
2
0.65
0.71
0.77
1.0 4.0
70
1558
2336
n/a
6230
9345
0.15
0.25
0.36
1/2
0
1
2
0.77
0.83
0.89
1.2 4.4
70
1186
1779
n/a
4743
7115
0.18
0.32
0.47
5/8
0
1
2
0.96
1.02
1.08
1.4 5.6
57
1205
1808
n/a
4820
7230
0.19
0.37
0.54
3/4
0
1
2
1.16
1.22
1.28
1.7 6.4
43
898
1347
n/a
3591
5387
0.31
0.53
0.74
1
0
1
2
1.47
1.53
1.63
2.1 7.1
43
718
1077
n/a
2872
4308
0.41
0.76
1.11
1 1/4
0
1
2
1.75
1.83
1.91
2.5 7.9
43
645
968
n/a
2581
3872
0.63
1.00
1.37
1 1/2
0
1
2
2.08
2.16
2.24
3.1 8.7
28
531
797
n/a
2125
3188
0.70
1.16
1.63
2
0
1
2
2.61
2.69
2.77
4.0 10.3
14
449
674
n/a
1797
2696
0.88
1.44
1.99
2 1/2
0
1
2
3.40
3.50
3.60
5.4 12.8
14
417
626
n/a
1669
2504
1.36
2.16
2.96
3
0
1
2
3.88
3.98
4.08
6.3 14.5
14
346
519
n/a
1384
2076
1.63
2.50
3.37
4
0
1
2
4.96
5.06
5.16
7.7 17.4
14
299
448
n/a
1194
1791
2.53
3.90
5.29
5
0
1
2
6.00
6.12
6.24
10.0 21.9
14
275
412
n/a
1099
1649
4.07
5.53
6.99
6
0
1
2
7.01
7.13
7.25
11.6 25.0
11
210
315
n/a
839
1259
4.46
6.34
8.22
10
