One Source, One System, One Solution.
www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
O-Ring Tube, Female, Swivel, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF90-0605 50605-0605 5/16 7.90 9/16-18 1.10
28
1.26
32
AC-OTF90-0606 50605-0606 5/16 7.90 5/8-18 1.10
28
1.06
27
AC-OTF90-0608 50605-0608 5/16 7.90 3/4-16 1.30
33
1.26
32
AC-OTF90-0806 50605-0806 13/32 10.30 5/8-18 1.30
33
1.26
32
AC-OTF90-0808 50605-0808 13/32 10.30 3/4-16 1.30
33
1.26
32
AC-OTF90-1008 50605-1008 1/2 12.70 3/4-16 1.50
38
1.50
38
AC-OTF90-1010 50605-1010 1/2 12.70 7/8-14 1.50
38
1.50
38
AC-OTF90-1012 50605-1012 1/2 12.70 1 1/16-14 1.77
45
1.77
45
AC-OTF90-1210 50605-1210 5/8 15.90 7/8-14 1.77
45
1.77
45
AC-OTF90-1212 50605-1212 5/8 15.90 1 1/16-14 1.77
45
1.77
45
AC-OTF90-1412 50605-1412 3/4 19.05 1 1/16-14 1.77
45
1.77
45
O-Ring Tube, Female, Swivel, 90 Block Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF90B-0808 50610-0808 13/32 10.30 3/4-16 0.75
19
0.94
24
AC-OTF90B-1010 50610-1010 1/2 12.70 7/8-14 0.75
19
0.98
25
AC-OTF90B-1210 50610-1210 5/8 15.90 7/8-14 0.75
19
0.98
25
O-Ring Tube, Female, Swivel, 180 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF180-0606 50615-0606 5/16 7.90 5/8-18 1.61
41
2.01
51
AC-OTF180-0808 50615-0808 13/32 10.30 3/4-16 1.73
44
2.01
51
AC-OTF180-1212 50615-1212 5/8 15.90 1 1/16-14 2.13
54
2.99
76
O-Ring Tube, Female, Swivel, Metric
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTFM-0616
50630-0616 5/16 7.90 16x1.5
1.54
39
AC-OTFM-0618
50630-0618 5/16 7.90 18x1.5
1.54
39
AC-OTFM-0620
50630-0620 5/16 7.90 20x1.5
1.54
39
AC-OTFM-0820
50630-0820 13/32 10.30 20x1.5
1.69
43
AC-OTFM-1022
50630-1022 1/2 12.70 22x1.5
1.69
43
AC-OTFM-1024
50630-1024 1/2 12.70 24x2.0
1.69
43
AC-OTFM-1227
50630-1227 5/8 15.90 27x2.0
1.81
46
– 10 –
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
