O-Ring Tube, Female, Swivel, Metric, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTFM45-0614 50633-0614 5/16 7.90 14x1.5 0.55 14 0.98 25
AC-OTFM45-0616 50633-0616 5/16 7.90 16x1.5 0.55 14 0.98 25
AC-OTFM45-0618 50633-0618 5/16 7.90 18x1.5 0.55 14 0.98 25
AC-OTFM45-0620 50633-0620 5/16 7.90 20x1.5 0.55 14 0.98 25
AC-OTFM45-0820 50633-0820 13/32 10.30 20x1.5 0.63 16 0.98 25
AC-OTFM45-1022 50633-1022 1/2 12.70 22x1.5 0.87 22 1.26 32
AC-OTFM45-1024 50633-1024 1/2 12.70 24x2.0 0.87 22 1.26 32
AC-OTFM45-1227 50633-1227 5/8 15.90 27x2.0 0.94 24 1.50 38
O-Ring Tube, Female, Swivel, Metric, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTFM90-0616 50635-0616 5/16 7.90 16x1.5 1.10 28 1.06 27
AC-OTFM90-0618 50635-0618 5/16 7.90 18x1.5 1.10 28 1.06 27
AC-OTFM90-0620 50635-0620 5/16 7.90 20x1.5 1.10 28 1.06 27
AC-OTFM90-0820 50635-0820 13/32 10.30 20x1.5 1.30 33 1.26 32
AC-OTFM90-1022 50635-1022 1/2 12.70 22x1.5 1.50 38 1.50 38
AC-OTFM90-1024 50635-1024 1/2 12.70 24x2.0 1.50 38 1.50 38
AC-OTFM90-1227 50635-1227 5/8 15.90 27x2.0 1.77 45 1.77 45
O-Ring Tube, Female, Swivel, R12 Valve
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF12V-0606 50650-0606 5/16 7.90 5/8-18 1.89 48 1/4 6.35
AC-OTF12V-0808 50650-0808 13/32 10.30 3/4-16 1.89 48 1/4 6.35
AC-OTF12V-1010 50650-1010 1/2 12.70 7/8-14 2.13 54 1/4 6.35
O-Ring Tube, Female, Swivel, R12 Valve, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF12V90-0606 50655-0606 5/16 7.90 5/8-18 1.10 28 2.13 54 1/4 6.35
AC-OTF12V90-0808 50655-0808 13/32 10.30 3/4-16 1.30 33 2.13 54 1/4 6.35
AC-OTF12V90-1010 50655-1010 1/2 12.70 7/8-14 1.50 38 2.36 60 1/4 6.35
AC-OTF12V90-1210 50655-1210 5/8 15.90 7/8-14 1.73 44 2.68 68 1/4 6.35
One Source, One System, One Solution. www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 11 –
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
