Page 11 - Layout 1

O-Ring Insert Male, R134a Valve
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIM134V-0606 50530-0606 5/16 7.90 5/8-18 2.44 62 0.63 16
AC-OIM134V-0808 50530-0808 13/32 10.30 3/4-16 2.56 65 0.63 16
AC-OIM134V-1010 50530-1010 1/2 12.70 7/8-14 1.77 45 0.51 13
AC-OIM134V-1212 50530-1212 5/8 15.90 1 1/16-14 2.95 75 0.51 13
O-Ring Insert Male, R134a Valve, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIM134V90-0606 50535-0606 5/16 7.90 5/8-18 1.61 41 2.13 54 0.63 16
AC-OIM134V90-0808 50535-0808 13/32 10.30 3/4-16 1.89 48 2.13 54 0.63 16
AC-OIM134V90-1010 50535-1010 1/2 12.70 7/8-14 2.13 54 2.36 60 0.51 13
O-Ring Tube, Female, Swivel
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF-0605 50600-0605 5/16 7.90 9/16-18 1.30 33
AC-OTF-0606 50600-0606 5/16 7.90 5/8-18 1.38 35
AC-OTF-0608 50600-0608 5/16 7.90 3/4-16 1.50 38
AC-OTF-0806 50600-0806 13/32 10.30 5/8-18 1.50 38
AC-OTF-0808 50600-0808 13/32 10.30 3/4-16 1.50 38
AC-OTF-1008 50600-1008 1/2 12.70 3/4-16 1.69 43
AC-OTF-1010 50600-1010 1/2 12.70 7/8-14 1.69 43
AC-OTF-1012 50600-1012 1/2 12.70 1 1/16-14 1.81 46
AC-OTF-1210 50600-1210 5/8 15.90 7/8-14 1.81 46
AC-OTF-1212 50600-1212 5/8 15.90 1 1/16-14 1.81 46
AC-OTF-1412 50600-1412 3/4 19.05 1 1/16-14 1.81 46
O-Ring Tube, Female, Swivel, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTF45-0606 50603-0606 5/16 7.90 5/8-18 0.55 14 0.83 21
AC-OTF45-0806 50603-0806 13/32 10.30 5/8-18 0.63 16 0.94 24
AC-OTF45-0808 50603-0808 13/32 10.30 3/4-16 0.63 16 0.94 24
AC-OTF45-1010 50603-1010 1/2 12.70 7/8-14 0.87 22 1.26 32
AC-OTF45-1210 50603-1210 5/8 15.90 7/8-14 0.94 24 1.50 38
AC-OTF45-1212 50603-1212 5/8 15.90 1 1/16-14 0.94 24 1.50 38
AC-OTF45-1412 50603-1412 3/4 19.05 1 1/16-14 0.94 24 1.50 38
Picture Not Available
Picture Not Available
One Source, One System, One Solution. www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 9 –
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
