O-Ring Insert Male, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIM45-0606 50503-0606 5/16 7.90 5/8-18 0.75
19
0.83
21
AC-OIM45-0808 50503-0808 13/32 10.30 3/4-16 0.98
25
0.94
24
AC-OIM45-1010 50503-1010 1/2 12.70 7/8-14 1.26
32
1.26
32
AC-OIM45-1212 50503-1212 5/8 15.90 1 1/16-14 1.38
35
1.50
38
AC-OIM45-1412 50503-1412 3/4 19.05 1 1/16-14 1.38
35
1.50
38
O-Ring Insert Male, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIM90-0606 50505-0606 5/16 7.90 5/8-18 1.50
38
1.06
27
AC-OIM90-0808 50505-0808 13/32 10.30 3/4-16 1.73
44
1.26
32
AC-OIM90-1010 50505-1010 1/2 12.70 7/8-14 2.01
51
1.50
38
AC-OIM90-1210 50505-1210 5/8 15.90 7/8-14 2.17
55
1.97
50
AC-OIM90-1212 50505-1212 5/8 15.90 1 1/16-14 2.52
64
2.36
60
AC-OIM90-1412 50505-1412 3/4 19.05 1 1/16-14 2.52
64
2.36
60
O-Ring Insert Male, Bulkhead
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIMB-0606
50515-0606 5/16 7.90 5/8-18
2.52
64
AC-OIMB-0808
50515-0808 13/32 10.30 3/4-16
2.76
70
AC-OIMB-1010
50515-1010 1/2 12.70 7/8-14
2.95
75
O-Ring Insert Male, Bulkhead, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OIMB90-0606 50520-0606 5/16 7.90 5/8-18 2.13
54
1.61
41
AC-OIMB90-0808 50520-0808 13/32 10.30 3/4-16 2.44
62
1.73
44
AC-OIMB90-1010 50520-1010 5/8 15.90 7/8-14 2.52
64
2.01
51
– 8 –
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
