1100 SERIES
0
1
DEFLECTION (inch)
2 3
2
4
6
0
1
DEFLECTION (inch)
ENERGY ABSORPTION
( ft - k i ps )
2 3
0.5
1.0
1.5
REACTION FORCE
(k i ps )
1104
1103
1103
1104
CHANNEL LOCK
Yet another unique Duramax® dock bumper design that is
produced in black, non-marking grey and white. A popular
design, especially in white! Duramax Marine® does not
supply channel and flat bar for this cross section but can
offer recommendations on a source of supply.
CODE NO. DURAMAX® BASE WIDTH WALL THICKNESS HEIGHT (H) WT./FT. LENGTH
PART NO. (W) (WT) RUBBER ONLY UP TO
DB-1103 802110301 3” 1 9/32” 3 1/4” 2.8 LBS. 60 FT.
DB-1104 802110401 4” 3/4” 4 5/16” 4.5 LBS. 40 FT.
H
W
WT
22
D-SHAPE / KEY BORE
CHANNEL LOCK
D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY B
