2100 SERIES
H
TW
W
0
3
DEFLECTION
(inch)
6
9
10
20
30
0
3
DEFLECTION
(inch)
ENERGY ABSORPTION
(f
t - k i ps )
6
9
5
10
15
REACTION FORCE
(k i ps )
2113
2113
2115
2110
2115
2117
2117
2110
TRAPEZOID
The trapezoidal fender is a robust multi-purpose extrusion.
Offered in black EPDM only.
TRAPEZO I D
www.DuramaxMarine.com
23
CODE NO.
DURAMAX
®
HEIGHT
TOP WIDTH
BASE WIDTH
WT./FT.
LENGTH
PART NO.
(H)
(TW)
(BW)
UP TO
DB-2110
802211001
10"
5 1/2"
12 3/4"
35
20 FT.
DB-2113
802211301
13"
7 3/8"
16 5/8"
59
20 FT.
DB-2115
802211501
15"
5 5/8"
19 1/8"
77
20 FT.
DB-2117
802211701
17"
9 7/8
21 5/8"
100
20 FT.
