Municipal
Woven Fire Hose
Ultima Lite
Polyester Double Jacket
Urethane Lined Fire Hose
Angus Ultima Lite is a lightweight hose that utilizes a thin,
high tensile thermoplastic lining to minimize weight. Both
the inner and outer jackets are constructed of polyester
warp yarns and filament polyester filler yarns. Ultima
Lite’s lining meets the NSF (National Sanitation
Foundation) Standard 61 for potable water and has a
tensile strength of over 5000 psi (35,000 kPa). Ultima
Lite is U.L. Listed. The standard color for Ultima Lite
Hose is white. Other colors available with our innovative
ARMOUR JACKET abrasion resistant coatings are red,
yellow, orange, blue, green and tan.
Premier
Nylon Double Jacket Rubber
Lined Fire Hose
Angus Premier is constructed of high strength, low stretch
entangled filament polyamide/cordura fibers over a rubber,
ozone proof, E.P.D.M. tube. Premier Hose is available
with our innovative ARMOUR JACKET abrasion resistant
coating. The standard colors are red, yellow, orange, blue,
green and tan.
Ultima
Polyester Double Jacket
Rubber Lined Fire Hose
Angus Ultima is the ultimate in quality, municipal grade
fire hose. This durable, double jacket hose is constructed
of 100% high tensile strength polyester yarns, both warp
and filler, and lined with a high-tech E.P.D.M. tube. Its
engineered design guarantees minimum weight with
maximum durability and flexibility. The standard color for
Ultima Hose is white. Other colors available with our
innovative ARMOUR JACKET abrasion resistant coatings
are red, yellow, orange, blue, green and tan.
Angus Premier
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 400 2800 800 5600 1200 8400 1-15/16 49 14 6.3 18 457
1-3/4 45 400 2800 800 5600 1200 8400 2-1/8 54 18 8.1 18 457
2-1/2 65 400 2800 800 5600 1200 8400 3 76 25 11.3 20 508
3 75 400 2800 800 5600 1200 8400 3-9/16 90 35 15.8 21 533
4 100 300 2100 600 4200 900 6300 4-17/32 115 41 18.6 25 635
Angus Ultima
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 400 2800 800 5600 1200 8400 1-15/16 49 15 6.8 18 457
1-3/4 45 400 2800 800 5600 1200 8400 2-1/8 54 22 9.9 18 457
2-1/2 65 400 2800 800 5600 1200 8400 3 76 31 14.0 21 533
3 75 400 2800 800 5600 1200 8400 3-9/16 90 42 18.9 21 533
Angus Ultima Lite
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 400 2800 800 5600 1200 8400 1-15/16 49 12 5.4 16 406
1-3/4 45 400 2800 800 5600 1200 8400 2-1/8 54 14 6.3 16 406
2-1/2 65 400 2800 800 5600 1200 8400 3 76 25 11.3 19 483
3 75 400 2800 800 5600 1200 8400 3-9/16 90 31 14.0 19 483
* Weight is uncoupled
Non-standard diameters available by special arrangement
