Page 9 - Angus_0406.qxd

Angus Hi-Power
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-3/4 44 11 5.0 13 330
1-3/4 45 300 2100 600 4200 900 6300 2 51 14 6.3 14 356
2 50 300 2100 600 4200 900 6300 2-3/16 56 18 8.1 14 356
2-1/2 65 300 2100 600 4200 900 6300 2-3/4 70 20 9.0 15 381
9
Red Chief
Lightweight Attack Hose
Angus Red Chief is a nitrile rubber through-the-weave
construction fire hose that is ideally suited for municipal
fire protection. Its synthetic jacket is completely protected
and locked in by a rubber cover and lining for extra
toughness and extra durability. The heavy rib construction
makes the hose highly resistant to cuts, punctures, impact
and abrasion. With a proof pressure of 600 psi (4200 kPa)
and a tolerance for temperatures from 1200°F to –37°F
(649°C to –38°C), Red Chief is clearly superior to all other
conventional fire hose constructions. Its lightweight
design is virtually non-kinking. U.L. labeling is available
on 1-1/2” and 2-1/2” at 200 PSI. The standard color for
Red Chief is red.
Yellow Chief
Lightweight Attack Hose
Angus Yellow Chief is a lightweight nitrile rubber through-
the-weave construction fire hose. Its synthetic jacket is
completely protected and locked in by a rubber cover and
lining for extra toughness and durability. A heavy rib
construction makes this hose resistant to cuts, punctures,
impact and abrasion. Yellow Chief is a 600 psi (4200 kPa)
fire hose that withstands temperatures from 1200°F to
–37°F, (649°C to –38°C). Its light-weight design is virtually
non-kinking and ideal for municipal fire protection. The
standard color for Yellow Chief is yellow.
Hi-Power
High Rise Fire Hose
Angus Hi-Power is an ultra-lightweight, maneuverable,
nitrile rubber hose designed specifically for fighting fires in
high rise buildings. The lightweight through-the-weave
construction is heat and puncture resistant, kink resistant
and has low friction loss. The rubber cover prevents water
from penetrating the reinforcement thus minimizing the
weight of the hose when in service. The standard color for
Hi-Power is blue.
Municipal
Rubber Covered Fire Hose
Angus Red Chief
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-13/16 46 17 7.7 16 406
1-3/4 45 300 2100 600 4200 900 6300 2-1/16 52 19 8.6 16 406
2 50 300 2100 600 4200 900 6300 2-5/16 59 21 9.5 17 432
2-1/2 65 300 2100 600 4200 900 6300 2-7/8 73 28 12.6 18 457
3 75 300 2100 600 4200 900 6300 3-13/32 87 35 15.8 18 457
Angus Yellow Chief
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1 25 300 2100 600 4200 900 6300 1-1/4 32 8 3.6 15 381
1-1/2 38 300 2100 600 4200 900 6300 1-13/16 46 16 7.3 16 406
1-3/4 45 300 2100 600 4200 900 6300 2-1/16 52 18 8.2 16 406
2 50 300 2100 600 4200 900 6300 2-5/16 59 20 9.1 17 432
2-1/2 65 300 2100 600 4200 900 6300 2-7/8 73 27 12.2 18 457
3 75 300 2100 600 4200 900 6300 3-13/32 87 33 15.0 18 457
* Weight is uncoupled
Factory Mutual Approved
