Angus M250
Single Jacket Polyester Mill
Hose
A heavy duty industrial mill hose, constructed of 100%
spun polyester for abrasive environments and low
maintenance. Designed for water discharge and other
low pressure applications such as washdown. The liner
is SBR for petrochemical resistance. The standard color
for Angus M250 is white.
Industrial
General Purpose Hose
Blue Skin
Lightweight Through-The-Weave
Washdown Hose
Angus Blue Skin is a layflat, lightweight, flexible
maintenance hose with the durability and abrasion
resistance of heavy duty rubber hose. Blue Skin features
a unique through-the-weave, one piece construction that
will not delaminate. The synthetic reinforcement is totally
encased in nitrile rubber cover and lining which is resistant
to fuels, chemicals, and oil. Blue Skin will not mildew or rot
and is heat and ozone resistant. The standard color for
Blue Skin is blue.
Armour Guard
Heavy Duty Rubber Covered
Industrial Discharge Hose
Angus Armour Guard is a layflat, flexible water discharge
hose with durability and abrasion resistance superior to
conventional rubber hose. Armour Guard features a
unique one piece, through-the-weave construction, and
attains its exceptional working pressure from a synthetic
woven textile. Its excellent durability is derived from a
high-tensile rubber compound which completely encases
the jacket. The standard color for Armour Guard is black.
Angus Blue Skin
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 225 1575 450 3150 750 5250 1-3/4 44 10 4.5 12 305
2 50 225 1575 450 3150 750 5250 2-3/16 56 15 6.8 13 330
2-1/2 65 225 1575 450 3150 750 5250 2-3/4 70 19 8.6 14 356
Angus Armour Guard
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-13/16 45 16 7.2 15 381
2 50 300 2100 600 4200 900 6300 2-3/16 56 20 9.0 16 406
2-1/2 65 300 2100 600 4200 900 6300 2-7/8 73 25 11.3 17 432
3 75 300 2100 600 4200 900 6300 3-13/32 87 35 15.8 18 457
4 100 200 1400 400 2800 600 4200 4-5/16 110 40 18.0 19 483
6 150 200 1400 400 2800 600 4200 6-3/8 162 80 36.0 21 533
Angus M250
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1 25 125 875 250 1750 500 3500 1-1/4 32 8 3.6 13 330
1-1/2 38 125 875 250 1750 500 3500 1-11/16 43 10 4.5 14 356
2 50 125 875 250 1750 500 3500 2-3/8 60 16 7.2 15 381
2-1/2 65 125 875 250 1750 500 3500 2-11/16 68 20 9.0 15 381
3 75 125 875 250 1750 500 3500 3-3/8 86 27 12.2 17 432
* Weight is uncoupled
