Angus RR500
Polyester Single Jacket Rack
and Reel Hose
This interior fire protection hose is designed to replace
unlined linen length for length. This polyester, urethane
lined hose is ideal for interior rack or reel service. Angus
RR500 is available folded for standard pin racks in 50'
(15m), 75’ (22.5m), and 100’ (30m) lengths. Specify
folded, coiled, or number of pins for rack (15 pins for 50’,
20 pins for 75’, or 25 pins for 100’). The standard color
for Angus RR500 is white. UL label and FM approval is
available. UL / FM hose is rated at 150 PSI service
pressure.
Industrial
Woven and Rubber Fire Hose
Redskin 500
Through-The-Weave Industrial
Fire Hose
Angus Redskin 500 is a layflat, lightweight, flexible fire
hose specifically designed for industrial fire protection.
Redskin is U.L. approved and features a unique through-
the-weave, one piece construction that will not
delaminate. The synthetic reinforcement is totally
encased in a PVC nitrile rubber cover and lining which is
resistant to fuels, oils, chemicals, abrasion, heat, mildew,
rot, and ozone. The standard colors for Redskin 500 are
red and yellow.
Redskin 600
Through-The-Weave Industrial
Fire Hose
Angus Redskin 600 is a layflat, lightweight, flexible fire
hose specifically designed for industrial fire protection.
Redskin is U.L. approved and features a unique through-
the-weave, one piece construction that will not
delaminate. The synthetic reinforcement is totally
encased in a PVC nitrile rubber cover and lining which is
resistant to fuels, oils, chemicals, abrasion, heat, mildew,
rot, and ozone. The standard colors for Redskin 600 are
red and yellow.
Angus Redskin 500
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 250 1750 500 3500 750 5250 1-3/4 44 10 4.5 12 305
1-3/4 45 250 1750 500 3500 750 5250 2 51 14 6.3 14 356
2-1/2 65 250 1750 500 3500 750 5250 2-3/4 70 19 8.6 14 356
3 75 250 1750 500 3500 750 5250 3-13/32 87 35 15.8 18 457
Angus Redskin 600
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-3/4 44 10 4.5 12 305
1-3/4 45 300 2100 600 4200 900 6300 2 51 14 6.3 14 356
2-1/2 65 300 2100 600 4200 900 6300 2-3/4 70 19 8.6 14 356
3 75 300 2100 600 4200 900 6300 3-13/32 87 35 15.8 18 457
Angus RR500
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 250 1750 500 3500 750 5250 1-11/16 43 5 2.3 12 305
* Weight is uncoupled
Factory Mutual Approved
