Angus D700
Polyester Double Jacket
Rubber Lined Fire Hose
This heavy duty double jacket industrial fire hose is
designed for daily use where higher pressure and
additional abrasion resistance is required. Construction
of 100% high tensile strength virgin polyester yarns, both
warp and filler, provides extra durability. Hose comes
standard with E.P.D.M. lining. The standard color for
Angus D700 Hose is white. Other colors available with
our innovative ARMOUR JACKET abrasion resistant
coatings are red, yellow, orange, blue, green and tan.
Angus S600
Polyester Single Jacket
Rubber Lined Fire Hose
A single jacket, polyester industrial fire hose with an
ozone-resistant E.P.D.M. rubber lining. The spun
polyester yarn in the jacket offers superior strength and
wear characteristics. Designed for interior or exterior fire
protection, Angus S600 is NFPA compliant as an attack
hose. The polyester construction is mildew resistant.
The standard color for Angus S600 Hose is white. Other
colors available with our innovative ARMOUR JACKET
abrasion resistant coatings are red, yellow, orange, blue,
green and tan.
Angus S500
Polyester Single Jacket Rubber
Lined Fire Hose
A single jacket, polyester industrial fire hose with an
ozone-resistant E.P.D.M. rubber lining. The spun
polyester yarn in the jacket offers superior strength and
wear characteristics. The polyester construction is
mildew resistant. The standard color for Angus S500
Hose is white. Other colors available with our innovative
ARMOUR JACKET abrasion resistant coatings are red,
yellow, orange, blue, green and tan.
Angus S300
Polyester Single Jacket Rubber
Lined Fire Hose
A single jacket, polyester industrial fire hose with an
ozone-resistant E.P.D.M. rubber lining. The spun
polyester yarn in the jacket offers superior strength and
wear characteristics. The polyester construction is
mildew resistant. The standard color for Angus S300
Hose is white. Other colors available with our innovative
ARMOUR JACKET abrasion resistant coatings are red,
yellow, orange, blue, green and tan.
Industrial
Woven Fire Hose
Angus D700
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-15/16 49 15 6.8 18 457
1-3/4 45 300 2100 600 4200 900 6300 2-1/8 54 22 9.9 18 457
2-1/2 65 300 2100 600 4200 900 6300 3 76 31 14.0 21 533
3 75 300 2100 600 4200 900 6300 3-9/16 90 38 17.1 21 533
Angus S600
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-13/16 46 11 5.0 15 381
2-1/2 65 300 2100 600 4200 900 6300 2-7/8 73 22 9.9 16 406
Angus S500
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 250 1750 500 3500 750 5250 1-13/16 46 11 5.0 15 381
2-1/2 65 250 1750 500 3500 750 5250 2-7/8 73 22 9.9 16 406
Angus S300
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 150 1050 300 2100 450 3150 1-13/16 46 11 5.0 15 381
2-1/2 65 150 1050 300 2100 450 3150 2-7/8 73 22 9.9 16 406
* Weight is uncoupled
Factory Mutual Approved
