BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
30
KRHCA0109
Food
T408LL - 240 PSI Food & Beverage Suction &
Discharge Hose
COUPLING SUGGESTIONS
Quick-Acting couplings attached with bands.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
APPLICATION
Food and alcoholic beverage suction and discharge. Specially
designed for wine, beer and spirits, up to 95 proof.
Hose may be sterilized with 30 PSI steam at 266°F for 30
minutes maximum – open end only.
Not recommended for dry abrasive materials.
COVER
White EPDM — abrasion and ozone resistant.
REINFORCEMENT
High tensile textile cords with embedded
nylon
helix.
TUBE
White, nontoxic chlorobutyl rubber. Meets FDA and 3A
requirements.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C).
STANDARD LENGTH
100 feet
BRANDING
ALFAGOMMA – ITALY T408 16 BAR (240 PSI) – FOOD
SUCTION & DELIVERY – CRUSH RESISTANT (in black
letters)
H
T408LL100
1
25
1.46
37
58
240
5
T408LL150
1 1/2
38
2.05
52
99
240
7 1/2
T408LL200
2
51
2.64
67
149
240
10
T408LL300
3
76
3.70
94
225
240
15
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
RADIUS (in.)
CONSULT FOOD HOSE GUIDE FOR MATERIAL COMPATIBILITY ON PAGE 31
