BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
28
KRHCA0109
Food
T452LE - 150 PSI PotableWater Hose
APPLICATION
Discharge of water used for drinking. Most often used for
temporary water lines in construction and industrial applications.
COVER
Blue SBR/EPDM blend — abrasion and ozone resistant.
REINFORCEMENT
High tensile textile cords.
TUBE
White NR. Meets FDA requirements.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C).
STANDARD LENGTH
100 feet
BRANDING
ALFAGOMMA – ITALY T452 “POTABLE WATER HOSE” 150
PSI WP (in white letters)
COUPLING SUGGESTIONS
Quick-Acting couplings attached with bands.
H
Kuriyama offers a full line of Quick-Acting couplings. Refer to current Kuriyama-Couplings™ and Accessories Catalog for type
and pricing.
T452LE150
1 1/2
38
1.97
50
72
150
T452LE200
2
51
2.56
65
113
150
T452LE250
2 1/2
63
3.03
77
136
150
T452LE300
3
76
3.62
92
188
150
T452LE400
4
102
4.65
118
251
150
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
HOSE IS NOT NSF APPROVED.
CONSULT FOOD HOSE GUIDE FOR MATERIAL COMPATIBILITY ON PAGE 31
