BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
12
KRHCA0109
Compressed Air
T902AA -150 PSI High Quality Hot Air
Blower Hose
APPLICATION
Hot air transfer between the air compressor and dry bulk tank
on bulk material carriers.
COVER
Black EPDM rubber — heat, abrasion and ozone resistant.
REINFORCEMENT
Spiralled high tensile textile cords and
4
highly fexible steel
helix wires.
TUBE
Black heat-resistant EPDM rubber.
TEMPERATURE RANGE
-40°F (-40°C) to 350°F (+180°C)
STANDARD LENGTH
100 feet
WORKING PRESSURE
Constant Pressure — 10 Bar (150 PSI)
BRANDING
ALFAGOMMA – ITALY T902 10 BAR (150 PSI) – HOT AIR
SERVICE (in white letters)
COUPLING SUGGESTIONS
Quick-Acting, pin lug, short shank couplings or combination nipples attached with single bolt, double bolt, wire or band type clamps.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T902AA200
2
51
2.48
63
99
6
T902AA300
3
76
3.54
90
157
9
T902AA400
4
102
4.65
116
216
12
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
RADIUS (in.)
