164 / 180
162
DQC116
877.963.4966 •
dixonvalve.comCM-Series Hydraulic Couplings
Body
Size
CM-Series Industrial Mold Interchange Valved Coupler (90º Hose Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CM9S2-B
1/4"
brass
$19.76
1.98 50.3 0.69 17.5 -
0.14 10 100
1/4"
2CM9S2.5-B 5/16"
brass
19.76
1.98 50.3 0.69 17.5 -
0.14 10 100
1/4"
2CM9S3-B
3/8"
brass
19.76
2.17 55.1 0.69 17.5 -
0.15 10 100
3/8"
3CM9S3-B
3/8"
brass
24.94
2.84 72.1 0.95 24.1 -
0.31 10 50
3/8"
3CM9S4-B
1/2"
brass
24.94
2.85 72.4 0.95 24.1 -
0.35 10 50
Body
Size
CM-Series Industrial Mold Interchange Unvalved Coupler (90º Push-Loc Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CM9B2-B-E
1/4"
brass
$15.81
2.07 52.6 0.69 17.5 -
0.14 10 100
1/4"
2CM9B3-B-E
3/8"
brass
15.81
2.17 55.1 0.69 17.5 -
0.16 10 100
3/8"
3CM9B3-B-E
3/8"
brass
21.78
2.93 74.4 0.95 24.1 -
0.37 10 50
3/8"
3CM9B4-B-E
1/2"
brass
21.78
2.98 75.7 0.95 24.1 -
0.37 10 50
1/2"
4CM9B4-B-E
1/2"
brass
39.96
3.50 88.9 1.18 30.0 -
0.83 5 30
1/2"
4CM9B6-B-E
3/4"
brass
39.96
3.50 88.9 1.18 30.0 -
0.83 5 30
Body
Size
CM-Series Industrial Mold Interchange Valved Coupler (90º Push-Loc Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CM9B2-B
1/4"
brass
$20.44
2.07 52.6 0.69 17.5 -
0.14 10 100
1/4"
2CM9B3-B
3/8"
brass
20.44
2.17 55.1 0.69 17.5 -
0.17 10 100
3/8"
3CM9B3-B
3/8"
brass
29.63
2.93 74.4 0.95 24.1 -
0.37 10 50
3/8"
3CM9B4-B
1/2"
brass
29.63
2.98 75.7 0.95 24.1 -
0.39 10 50
