161 / 180
159
DQC116
877.963.4966 •
dixonvalve.comCM-Series Hydraulic Couplings
Body
Size
CM-Series Industrial Mold Interchange Unvalved Coupler (Hose Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CMS2-B-E
1/4"
brass
$10.11
2.11 53.6 0.69 17.5 -
0.10 10 100
1/4"
2CMS2.5-B-E 5/16"
brass
10.11
2.10 53.3 0.69 17.5 -
0.09 10 100
1/4"
2CMS3-B-E
3/8"
brass
10.11
2.10 53.3 0.69 17.5 -
0.11 10 100
3/8"
3CMS3-B-E
3/8"
brass
13.02
2.55 64.8 0.95 24.1 -
0.24 10 50
3/8"
3CMS4-B-E
1/2"
brass
13.02
2.55 64.8 0.95 24.1 -
0.25 10 50
1/2"
4CMS4-B-E
1/2"
brass
29.76
2.98 75.7 1.18 30.0 -
0.46 5 30
1/2"
4CMS6-B-E
3/4"
brass
29.76
2.98 75.7 1.18 30.0 -
0.48 5 30
Body
Size
CM-Series Industrial Mold Interchange Valved Coupler (Hose Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CMS2-B
1/4"
brass
$11.59
2.66 67.6 0.69 17.5 -
0.10 10 100
1/4"
2CMS2.5-B
5/16"
brass
11.68
2.66 67.6 0.69 17.5 -
0.10 10 100
1/4"
2CMS3-B
3/8"
brass
17.17
2.66 67.6 0.69 17.5 -
0.10 10 100
3/8"
3CMS3-B
3/8"
brass
17.50
3.30 83.8 0.95 24.1 -
0.27 10 50
3/8"
3CMS4-B
1/2"
brass
17.50
3.28 83.3 0.95 24.1 -
0.28 10 50
Body
Size
CM-Series Industrial Mold Interchange Unvalved Coupler (Push-Loc Barb)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Hose ID
Material
Inch mm Inch mm
Bag Box
1/4"
2CMB2-B-E
1/4"
brass
$11.23
2.08 52.8 0.69 17.5 -
0.10 10 100
1/4"
2CMB3-B-E
3/8"
brass
11.23
2.08 52.8 0.69 17.5 -
0.11 10 100
3/8"
3CMB3-B-E
3/8"
brass
15.16
2.53 64.3 0.95 24.1 -
0.26 10 50
3/8"
3CMB4-B-E
1/2"
brass
15.16
2.69 68.3 0.95 24.1 -
0.25 10 50
1/2"
4CMB4-B-E
1/2"
brass
29.76
3.12 79.2 1.18 30.0 -
0.50 5 30
1/2"
4CMB6-B-E
3/4"
brass
29.76
3.12 79.2 1.18 30.0 -
0.51 5 30
