176

DQC116

877.963.4966 •

dixonvalve.com

Part Number Structure

Seals

F FKM

TM

P EPDM

E Neoprene

S Silicone

U Urethane

H Aflas

TM

K4 Kalrez

®

4079

K6 Kalrez

®

6375

K7 Kalrez

®

7075

M Military Low Temp Nitrile

JF Hydrocarbon Fuel Nitrile

T PTFE

TS PTFE / Silicone

D FDA FKM

TM

FS Fluorosilicone

PS EPDM (steam)

M1 Nitrile (FDA)

C Celazole Back-up

CZ Chemrez

Standard seal is Nitrile. No

designation is necessary for

standard Nitrile seal

configurations.

1 1/8"

1.25 4mm

1.5 3/16"

1.88 6mm

2 1/4"

2.5 5/16"

2.83 9mm

3 3/8"

4 1/2"

5 5/8"

6 3/4"

8 1"

10 1-1/4"

12 1-1/2"

16 2"

20 2-1/2"

24 3"

End Size

Materials

A Aluminum

B Brass

NB Naval Brass

SB Stress Relieved Brass

S 303 Stainless Steel

SS 316 Stainless Steel

SN Nitronic Stainless

P Plastic

Standard material is steel.

No designation is

necessary for standard

steel configurations.

Valve Options

E Unvalved (no valve)

V Valved

BV Brass Valve

SV 303 SS Valve

SSV 316 SS Valve

PV Poppet Valve

VA Valve Actuator

HV Heavy Duty Valving

TV Tube Valve

BTV Brass Tube Valve

RV Prong Valve

A Perfecting Astronautics High Pressure Pneumatic

AG Agricultural Interchange Hydraulic

BR Rectus 21 Interchange

CJ European High Flow Interchange

CM Mold Coolant Interchange

CVV European Screw Together

DF Industrial Interchange Pneumatic

E Straight-Through Pressure Wash Interchange

EA Straight-Through Water-Blast Interchange

H ISO-B Industrial Interchange

HS ISO-B Steam Interchange

HT ISO16028 Flushface Interchange

J Truflate Automotive Interchange

K ISO-A Mobile Interchange

L Lincoln Long-Stem Interchange

M ARO 210/310 Interchange

N Bowes Interchange

NK Japanese Industrial Interchange

P Thor Interchange

SCV Excessive Flow Sensor/Safety Check Valve

ST Snap-Tite 71 Flushface Interchange

SHD Rectus 17/Schrader Interchange

T High Pressure Screw Together

TR TEMA European Interchange

U Universal Pneumatic Combo-Couplers

V Snap-Tite H/IH Hydraulic Interchange

VEP Stucchi VEP Hydraulic Interchange

W Wingstyle Interchange

WS High Pressure Wingstyle

Product Series

Many variations of the part numbers contained within this guide can be ordered utilizing the format shown above. However, some

variations may require minimum order quantities, longer lead times, and/or price adjustments based upon the uniqueness of

construction. Please contact your Dixon Quick Coupling representative for details regarding your particular coupling configuration

To Designate Couplers

Body size numerical designation precedes coupling

series alpha designation. Example: 2HF2 (1/4"

ISO-B Coupler)

To Designate Nipples

Coupling series alpha designation precedes body

size numerical designation. Example: H2F2 (1/4"

ISO-B Nipple)

FKM

TM

Kalrez

®

is a trademark of Dupont/Dow Elastomers

PTFE is a trademark of Dupont

Aflas

®

is a trademark of Asahi Glass Limited

1 1/8"

1.25 4mm

1.5 3/16"

1.88 6mm

2 1/4"

2.5 5/16"

2.83 9mm

3 3/8"

4 1/2"

5 5/8"

6 3/4"

8 1"

10 1-1/4"

12 1-1/2"

16 2"

20 2-1/2"

24 3"

Body Size

End Connection

F Female NPT(F)

M Male NPT(F)

BF Female BSPP

BM Male BSPT

GM Male BSPP

OF Female ORB

OM Male ORB

JF Female 37° JIC

JM Male 37° JIC

JB Male Bulkhead 37° JIC

RM Male ORFS

RB Bulkhead ORFS

P Tube Fitting

S Hose Barb

4S 45° Hose Barb

9S 90° Hose Barb

CS Collar Hose Barb

B Push-Loc Barb

4B 45° Push-Loc Barb

9B 90° Push-Loc Barb

FM Female Metric

MM Male Metric

MBM Metric Bulkhead

Sleeve Options

LS Locking Sleeve

BLS Brass Locking Sleeve

ZLS Steel Locking Sleeve

XLS 303 SS Locking Sleeve

YLS 316 SS Locking Sleeve

FS Flanged Sleeve

BFS Brass Flanged Sleeve

FLS Flanged Locking Sleeve

ZFS Steel Flanged Sleeve

FSB Silicone Fryer Boot

BS Brass Sleeve

ZS Steel Sleeve

XS 303 SS Sleeve

YS 316 SS Sleeve

PTC Push-To-Connect Sleeve

TG Thermal Guard Sleeve

PL Automatic Latch Pin

PB Automatic Ball Latch

TG Thermal Guard Sleeve

HN Hex Nut Sleeve

HNS 303 SS Hex Nut Sleeve

TP Tangle Prevention

FNS Flanged Nylon Sleeve

NLS No Locking Sleeve

Other Options

4 Black Oxide Plating

7 Bright Nickel Plating

8 Electroless Nickel Plating

9 PTFE Coating

10 Standard Nickel Plating

11 Chrome over Nickel

BMF Flange Mount Bracket

C1 Oxygen Clean

HL Extended Hex

L## Length

WF Wrench Flats

F - 4 H F 4 - B - E - LS - 7
