Male JIC x Male NPTF Adaptor
Female JIC Straight Insert
A male JIC B male NPT
7/16
1/4
1/2
1/4
3/4
3/8
7/8
1/2
11/16
3/4
15/16
1
15/8
11/4
17/8
11/2
Male JIC x Female NPTF Adaptor
A B Ø for hose
(inch)
(inch)
(mm)
7/16
1/4
6,35
1/2
1/4
6,35
3/4
3/8
9,52
7/8
1/2
12,7
11/16
3/4
19,05
15/16
1
25,4
15/8
11/4 31,75
17/8
11/2 38,10
Female JIC Elbow 45º Insert
A male JIC B male NPT
7/16
1/4
1/2
1/4
3/4
3/8
7/8
1/2
11/16
3/4
15/16
1
15/8
11/4
17/8
11/2
A B Ø for hose
(inch)
(inch)
(mm)
7/16
1/4
6,35
1/2
1/4
6,35
3/4
3/8
9,52
7/8
1/2
12,7
11/16
3/4
19,05
15/16
1
25,4
15/8
11/4 31,75
17/8
11/2 38,10
Insert Female JIC Elbow 90º
A B Ø for hose
(inch)
(inch)
(mm)
7/16
1/4
6,35
1/2
1/4
6,35
3/4
3/8
9,52
7/8
1/2
12,7
11/16
3/4
19,05
15/16
1
25,4
15/8
11/4 31,75
17/8
11/2 38,10
Insert Male NPT
A B Ø for hose
(inch) (inch) (mm)
7/16 1/4 6,35
1/2 1/4 6,35
3/4 3/8 9,52
7/8 1/2 12,7
11/16 3/4 19,05
15/16 1 25,4
15/8 11/4 31,75
17/8 11/2 38,10
Male Gas / Female Gas
A B
(thread) (mm)
1/4” 6
3/8” 8
3/8” 10
1/2” 10
1/2” 13
5/8” 16
3/4” 19
1” 25
11/2” 38
19
MALE JIC x MALE NPTF ADAPTOR
FEMALE JIC STRAIGHT INSERT
MALE JIC x FEMALE NPTF ADAPTOR
INSERT FEMALE JIC ELBOW 90º
FEMALE JIC ELBOW 45º INSERT
INSERT MALE NPT
MALE GAS
FEMALE GAS
