Aluminum Valves & Wyes
B
Aluminum Valves & Wyes
Global Aluminum Hydrant Gate Valve with Speed Handle
Dixon Northline Aluminum Hydrant Gate Valves
with Speed Handle
male x female
female x male
The primary purpose of a single hydrant gate valve is to protect fire hydrants from damage that
can occur if they are used for throttling.
•pin lug swivel, non-rising stem, aluminum speed handle
•material: aluminum
•non-metalic seal
•for use up to 175 PSI (water only)
Description Part # Wt.
Lbs.
speed handle AHGV250F-H 1.0
Replacement Part
Inlet
Female NH (NST)
Outlet
Male NH (NST) Part # Wt.
Lbs.
2½" 2½" AHGV250F-I 3.75
The primary purpose of a single hydrant gate valve is to protect fire hydrants from damage that
can occur if they are used for throttling.
•full 2½" waterway
•body of valve - high strength aluminum alloy, 356-T6
•hardcoat anodized throughout - minimum thickness 0.001 inch
• 250 PSI test pressure, 100 PSI working pressure
Inlet
Female Swivel
Outlet
Male Part # Wt.
Lbs.
2½" NPSH
2½" NST
2½"
2½" NPSH
2½" NST
2½"
AHGV250
AHGV250F
AHGV250___ *
5.0
5.0
5.0
* customer to specify thread
