Application:
• The breaking bolt industrial breakaway coupling is designed to minimize spillage and damage associated with drive away and pull
away incidents.
Features:
• designed to be installed between a fixed point (pipe, pump, manifold) and a hose
• coupling automatically senses an excessive load, closes the valves and disconnects
•female NPT is standard, optional ANSI / DIN flanges or male NPT are available
•high flow rate / low pressure drop
• working pressure: stainless steel 360 PSI and
aluminum 230 PSI at ambient temperature (70°F)
• Viton® is standard seal
Industrial Version
Size DN 316 Stainless Steel Aluminum
Part # Price/E Part # Price/E
2" 50 SBC200SS $3667.85 SBC200AL $1711.90
3" 80 SBC300SS 6484.90 SBC300AL 3324.85
4" 100 SBC400SS 9960.10 SBC400AL 5085.10
5" 125 SBC500SS 18798.00 SBC500AL 11746.00
6" 150 SBC600SS 33608.90 SBC600AL 24709.70
c
Safety Break-away Coupling - Breaking Bolt Series
Optional Non-Closure Design
The non-closure design is an economical alternative which allows the coupling to break away due to pull-away/drive-away incidents
thus protecting piping systems and equipment. This design allows spillage of product in these instances due to the lack of valving in
the coupling. Useful in applications where non-hazardous product is being conveyed and where there are no environmental concerns.
Available in both Industrial and Marine versions. Consult the factory for more information.
How it Works
Safety break-away couplings have three external break bolts. In the case of axial tension all of the bolts take up the force
corresponding to the break force on the hose with a safety margin. Non-axial forces concentrate the tension forces more strongly
on one bolt, so that the safety break-away coupling reacts in a natural way to the reduction of the hose break forces.
The safety break-away valve consists of two halves, each with a
valve that has a O-ring seal.
BEFORE emergency disconnect
When the safety break-away couplings separate, it allows the
valves to close. The two valves close rapidly, minimizing exposure
to personnel and the environment.
AFTER emergency disconnect
Size Width Length Weight in Lbs. Flow Rate/GPM
Stainless Aluminum
2"
3"
4"
5"
6"
8"
4.5"
6.8"
8.3"
10.6"
12"
13.5"
7"
11"
12"
14"
16"
17.7"
5
18
34
71
101
157
3
8
14
27
35
66
200
650
800
1100
1500
3700
Female NPT x Female NPT
Size DN 316 Stainless Steel Aluminum
Part # Price/E Part # Price/E
2" 50 SBC200SSMNPT $3850.80 SBC200ALMNPT $1891.30
3" 80 SBC300SSMNPT 7044.00 SBC300ALMNPT 3610.70
4" 100 SBC400SSMNPT 10818.00 SBC400ALMNPT 5523.40
5" 125 SBC500SSMNPT 19352.00 SBC500ALMNPT 10744.00
6" 150 SBC600SSMNPT 36453.00 SBC600ALMNPT 24043.00
Male NPT x Male NPT
Size DN 316 Stainless Steel Aluminum
Part # Price/E Part # Price/E
2" 50 SBC200SSFL $5181.35 SBC200ALFL $3512.40
3" 80 SBC300SSFL 10602.00 SBC300ALFL 4512.70
4" 100 SBC400SSFL 16172.00 SBC400ALFL 5576.30
5" 125 SBC500SSFL 21566.00 SBC500ALFL 12832.00
6" 150 SBC600SSFL 35420.00 SBC600ALFL 25912.00
8" 200 SBC800SSFL 76732.20 --- ---
150# Flange x 150# Flange
