Maintenance & Repair
T
669 DPL413 877.963.4966 • dixonvalve.com
CI96 CI96AH
Coupling Inserters
Hand Hydrotest Pump
Coupling Inserter for Large Hose
Features:
• portable
•inserts 4", 5", 6", 8", 10" and 12" couplings
• includes CI96AH pump (shown below)
• coupling inserter pusher plates (not shown) must be
purchased separately
Part # Price/E
CI9 $5335.00
Hose ID Part # Price/E
4" - 5" 45CIPUSH $300.00
6" - 8" 68CIPUSH 380.00
10" - 12" 1012CIPUSH 530.25
Application:
• for insertion of hose shanks into hose with a 2¾" to 7¼" OD
Description Part # Price/E
Supplied with a 10,000 PSI hand
pump and 5 ton ram CI96 $6165.00
Supplied with a 10,000 PSI air/
hydraulic pump and 5 ton ram CI96AH 7310.00
Small jaws for 1" to 3" OD hose CI9311SML 185.00
Application:
• designed for use in testing pipe lines, pressure tanks and
pressure vessels
Features:
•stainless steel piston, aluminum body
•uses efficient and long lasting check valves
•cylinder displacement: 1.37 cubic inches
•0-1000 PSI pressure gauge, 10' pressure hose and quick
disconnect coupler included
• piston: 7/8" with 2" stroke
Inlet
NPT
Outlet
NPT
Working
Pressure
PSI
Part # Price/E
½" ½" 1000 HHTP $1946.00
Hung Up On Dixon Hose Racks
DHR2
double hose rack
(hose not included)
DHR1
single hose rack
Application:
•can be used for fire or water hose
Features:
• aluminum rack can be easily mounted
• single and double racks have 5 pre-drilled 5/16" mounting holes
• two racks can be bolted face to face to create extra hose capacity
• single rack overall dimensions 19-1/2" x 6" x 9-3/16"
• double rack overall dimensions 19-1/2" x 12" x 9-3/16"
Description Weight (lbs.) Part # Price/E
single hose rack 3.5 DHR1 $218.00
double hose rack 9.5 DHR2 452.00
