Tank Truck Fittings
R
641 DPL413 877.963.4966 • dixonvalve.com
11¾"
23¾"
Side Seal Drop Elbow
Coaxial Drop Elbow
Side Seal Adapter
Features:
• for single point vapor recovery only
• 3" male vapor outlet (top)
• comes assembled with 4" male inlet
• 6400 co-axial inlets do not fit our other elbow series
• quality cast aluminum construction with solid bronze arms
•bolt-on inlets/outlets for easy, fast replacement
• acrylic sight glass with buna seals
• replacement parts are available, please contact Dixon
Description Aluminum
Part # Price/E
4" male inlet 6400 $1324.20
Features:
•for use with special 4" side seal style fill collars only
•modular, easy to repair, bolt together aluminum construction
•comes with acrylic sight glass with buna seals (2), bronze
locking levers and buna main seal
• 4" male adapter inlet and lock ring installed
• replacement parts are available, please contact Dixon
Description Aluminum
Part # Price/E
side seal elbow with lock
ring and 4" male adapter
inlet
6000ASAL $805.55
Features:
• allows conventional elbows to be used with special side seal
style fill collars
•bottom connects to side seal fill collar
•top section with standard 4" top seal collar profile to accept
clamping of standard 4" drop elbows
• replacement parts are available, please contact Dixon
Description Aluminum
Part # Price/E
4" top seal drop elbow
adapter x side seal
connection
6000-SSA $366.15
Coaxial Drop Elbow Replacement Fuel Inlets
Description Aluminum
Part # Price/E
3" adapter fuel inlet 6000-16C $72.50
4" adapter fuel inlet 6000-17C 72.50
3" coupler fuel inlet 6000-15C 134.00
4" coupler fuel inlet 6000-14C 128.10
Features:
• for 6400 series coaxial elbows only
•rated for petroleum service, Ethanol to E100 and biodiesel
to B20
