Air Fittings
E
249 DPL413 877.963.4966 • dixonvalve.com
Watts Regulators
SCFM ratings at 150 PSIG inlet pressure.
Standard
Standard
Features:
• 2 - 125 PSIG (.15 - 8.5 bar)
range
• zinc body
• relieving
• diaphragm operated
• spring adjustment mechanism
• t-handle design
• supply pressure: 300 PSIG (20.4 bar)
maximum
• temperature range: 40°F (4.4°C) to
120°F (48.9°C)
• uses a GC230 gauge
Compact
Features:
• 2 - 125 PSIG (.15 - 8.5 bar)
range
• zinc body
• relieving
• diaphragm operated
• spring adjustment mechanism
• t-handle design
• brass bottom plug
• aluminum spring cage
• supply pressure: 300 PSIG (20.4 bar)
maximum
• temperature range: 40°F (4.4°C) to
120°F (48.9°C)
• uses a GC230 gauge
Features:
• 2 - 125 PSIG (.15 - 8.5 bar)
range
• zinc body
• relieving
• diaphragm operated
• spring adjustment mechanism
• t-handle design
• acetal bottom plug
• aluminum spring cage
• supply pressure: 300 PSIG (20.4 bar)
maximum
• temperature range: 40°F (4.4°C) to
120°F (48.9°C)
• uses a GC230 gauge
See page 253 for regulator accessories.
Features:
• 2 - 125 PSIG (.15 - 8.5 bar)
range
• brass body
• relieving
• diaphragm operated
• non-rising adjusting knob
• supply pressure: 300 PSIG (20.4 bar)
maximum
• temperature range: 40°F (4.4°C) to
120°F (48.9°C)
• 1/8" gauge port
Mini 2.56
(65) 3.06
(78)
.50
(13)
1.56
(40)
Size SCFM With Gauge Without Gauge
Part # Price/E Part # Price/E
1/4" 10 R364-02CG $78.00 R364-02C $57.30
Size SCFM With Gauge Without Gauge
Part # Price/E Part # Price/E
1/4" 60 R11-02CG $120.50 R11-02C $99.80
3/8" 70 R11-03CG 120.50 R11-03C 99.80
1/2" 80 R11-04CG 120.50 R11-04C 99.80
Size SCFM With Gauge Without Gauge
Part # Price/E Part # Price/E
1/4" 60 R119-02CG $141.75 R119-02C $121.05
3/8" 80 R119-03CG 141.75 R119-03C 121.05
1/2" 100 R119-04CG 165.00 R119-04C 144.30
Size SCFM With Gauge Without Gauge
Part # Price/E Part # Price/E
¾" 200 R119-06CG $261.00 R119-06C $240.30
1" 220 R119-08CG 261.00 R119-08C 240.30
1½" 250 R119-12CG 323.60 R119-12C 302.90
FRL's are designed for air service only, unless otherwise indicated.
