Air Fittings
E
DPL413 877.963.4966 • dixonvalve.com 248
Watts Filters
SCFM ratings at 150 PSIG inlet pressure.
Features:
• 40 micron polypropylene
element
• 16 oz. bowl
• zinc body
• automatic drain operating conditions:
temperature range: 40°F (4.4°C) to 120°F (48.9°C)
pressure: 175 PSIG (12 bar) maximum
• manual drain operating conditions:
temperature range: 40°F (4.4°C) to 150°F (65.6°C)
pressure: 250 PSIG (17 bar) maximum
Features:
• 40 micron polypropylene
element
• 26 oz. bowl
• aluminum body
• automatic drain operating conditions:
temperature range: 40°F (4.4°C) to 120°F (48.9°C)
pressure: 175 PSIG (12 bar) maximum
• manual drain operating conditions:
temperature range: 40°F (4.4°C) to 150°F (65.6°C)
pressure: 250 PSIG (17 bar) maximum
Watts Filter / Regulator
2.433
2.350
2.571
8.376
3.405
See page 252 for filter accessories.
Standard Zinc Bowl with Sight Glass
Size SCFM Automatic Drain Manual Drain
Part # Price/E Part # Price/E
1½" 380 F602-12WJR $427.65 F602-12WJ $367.40
Standard Zinc Bowl with Sight Glass
Size SCFM Automatic Drain Manual Drain
Part # Price/E Part # Price/E
2" 1125 F602-16WJR $1224.50 F602-16WJ $1166.35
Features:
• 2 - 125 PSIG (.15 - 8.5 bar)
range
• 40 micron filter
• 4 oz. bowl
• zinc body
• relieving
• diaphragm operated
• spring adjustment mechanism
• glass-filled acetal plastic spring cage
• tamper resistant, snap lock, removable
knobs
• temperature range: 40°F (4.4°C) to
120°F (48.9°C)
• uses a GC230 gauge (not supplied)
Zinc Bowl with Sight Glass
Size SCFM Automatic Drain Manual Drain
Part # Price/E Part # Price/E
1/4" 60 B11-02WJCR $272.05 B11-02WJC $211.80
3/8" 70 B11-03WJCR 272.05 B11-03WJC 211.80
1/2" 80 B11-04WJCR 272.05 B11-04WJC 211.80
FRL's are designed for air service only, unless otherwise indicated.
