Air Fittings
E
203 DPL413 877.963.4966 • dixonvalve.com
Features:
• 0-125 PSIG adjusting range
• 5 micron reusable element
• 5 oz. bowl
• self-relieving standard
• diaphragm operated
• quick-disconnect bowl guard with integral plastic bowl and
safety latch standard
• Two ¼" gauge ports are provided in either side of the
regulator body for installation of a gauge or to use as an
additional outlet port. Plug unused port(s).
• supplied with GC230 gauge
• maximum operating conditions:
transparent bowl: 150 PSIG (10.3 bar) and 32°F to 125°F
(0°C to 52°C)
metal bowl: 200 PSIG (13.8 bar) and 32°F to 150°F
(0°C to 65.5°C)
Wilkerson Compact Filter / Regulators
SCFM ratings at 100 PSIG inlet pressure.
Application:
Over-under units are space savers and provide for installation in tight areas. One common inlet/outlet for both filter and regulator
saves on piping costs.
with guard
Features:
• 0-125 PSIG adjusting range
• 5 micron element
• 4 oz. bowl
• self-relieving standard
• spring-loaded diaphragm
• To increase regulated pressure, pull adjusting knob and turn
clockwise. To reduce pressure, turn knob counter clockwise.
To lock knob, push down.
• Two ¼" gauge ports located on the front and rear faces of
the body. These ports may be used as additional regulated
ports or for pressure gauges. Plug unused port(s).
• supplied with GC230 gauge
• maximum operating conditions:
transparent bowl: 150 PSIG (10.3 bar) and 32°F to 125°F
(0°C to 52°C)
metal bowl: 250 PSIG (17.2 bar) and 32°F to 150°F
(0°C to 65.5°C)
2.36 (60)
10.00 (254)
3.66 (93)
1.60 (41)
Bowl Removal
Clearance with metal bowl
See page 221 for filter/regulator accessories.
Size SCFM
With Transparent Bowl and Guard With Metal Bowl with Sight Glass
Automatic Drain Manual Drain Automatic Drain Manual Drain
Part # Price/E Part # Price/E Part # Price/E Part # Price/E
1/4" 64.0 CB6-02AG $277.30 CB6-02MG $220.50 CB6-02AGMB $293.85 CB6-02MGMB $237.05
3/8" 70.0 CB6-03AG 277.30 CB6-03MG 220.50 CB6-03AGMB 293.85 CB6-03MGMB 237.05
1/2" 70.0 CB6-04AG 277.30 CB6-04MG 220.50 CB6-04AGMB 293.85 CB6-04MGMB 237.05
Size SCFM
With Transparent Bowl and Guard With Metal Bowl with Sight Glass
Automatic Drain Manual Drain Automatic Drain Manual Drain
Part # Price/E Part # Price/E Part # Price/E Part # Price/E
1/4" 88 B18-02AG $211.85 B18-02MG $155.05 B18-02AGMB $215.70 B18-02MGMB $158.90
3/8" 117 B18-03AG 211.85 B18-03MG 155.05 B18-03AGMB 215.70 B18-03MGMB 158.90
1/2" 121 B18-04AG 211.85 B18-04MG 155.05 B18-04AGMB 215.70 B18-04MGMB 158.90
FRL's are designed for air service only, unless otherwise indicated.
