8
Ultraflex
®
Ultraflex TPU –
Type TPU is constructed of a helical wire reinforced
thermoplastic urethane that offers excellent abrasion resistance for material handling
applications. It’s a tough, versatile, lightweight, flexible hose/ducting that can be used in a wide
variety of applications, and is offered in black or clear transparent urethane that allows the user to
monitor the flow of material.
Ultraflex VP –
Type VP is constructed of a vinyl coated polyester fabric material with a spring steel wire helix
reinforcement. This type also includes a vinyl wear strip over the wire helix for additional wear resistance. It is
offered in single ply construction (VP-1) or double ply construction (VP-2).
Standard Colors:
Black or Clear
Sizes:
2
"
I.D. through 18
" I
.D.
Standard Length:
25 ft. (other lengths up to 50 ft.
available upon request)
Temp. Range:
-65°F to +200°F
Features:
Superior abrasion resistance, excellent
low temperature flexibility, high tear
strength, excellent ozone resistance,
and good oil resistance.
Applications:
Lawn and garden applications include
chip handling, leaf and grass loading,
straw blowing; industrial vacuum
systems; transfer of plastic pellets; dry
bulk material handling systems;
agricultural product material handling;
woodworking applications include
transfer of sawdust and wood chips.
Standard Colors:
Yellow with orange wear strip
Sizes:
2
"
I.D. through 18
"
I.D.
Standard Length:
25 ft. (other lengths up to 50 ft.
available upon request)
Temp. Range:
-20°F to +180°F
Features:
Good chemical resistance, mildew
and moisture resistant, lightweight,
flexible, abrasion resistant, flame
retardant.
Applications:
Chemical and abrasion resistant,
designed for both positive and
negative low pressure air movement,
fume and dust removal and light
material handling.
Standard Colors:
Yellow with orange wear strip
Sizes:
2
"
I.D. through 18
" I
.D.
Standard Length:
25 ft. (other lengths up to 50 ft.
available upon request)
Temp. Range:
-20°F to +180°F
Features:
Good chemical resistance, mildew and
moisture resistant, lightweight,
flexible, abrasion resistant, flame retardant.
Applications:
Chemical and abrasion resistant,
designed for both positive and negative
low pressure air movement, fume and
dust removal and light material handling.
®
Type VP-1
Inside Diameter (inches)
2 4 6 8 10
Inside Bend Radius
1/2 of I.D.
Burst (Calculated)
55 27 18 14 11
Working Pressure (psig)
13.5 6.5 4.5 3.5 2.5
Compressibility
60%
Temperature Range
-20°F to +180°F
Max. Negative Pressure (in. hg.)
23 10
Footnote:
All pressure and vacuum data based on 72°F temperature.
Footnote:
All pressure and vacuum data based on 72°F temperature.
Type TPU
Inside Diameter (inches)
2 4 6 8 10
Weight (lbs./ft.)
.24 .56 .94 1.08 1.36
Inside Bend Radius
1/2 of I.D.
Burst (psig)
50 25 22 15 10
Working Pressure (psig)
17 8 7 5 3
Compressibility
65%
Temperature Range
-65°F to +200°F
Max. Negative Pressure (in. hg.) 24 23 9 8 6
Footnote:
All pressure and vacuum data based on 72°F temperature.
Type VP-2
Inside Diameter (inches)
2 4 6 8 10
Inside Bend Radius
Equals I.D.
Burst (Calculated)
80 40 27 21 16
Working Pressure (psig)
20 10 6.5 5 4
Compressibility
50%
Temperature Range
-20°F to +180°F
Max. Negative Pressure (in. hg.)
23 10
