7
For Assistance: 800/835-0682 or E-Mail: info@hbdthermoid.com
Standard Colors: Black
Sizes: 2" I.D. through 18 ".D.
Standard Length: 25 ft. (other lengths up to 50 ft.
available upon request)
Temp. Range: -60°F to +275°F Continuous.
+300°F Intermittent
Features: Excellent flexibility and
compressibility characteristics;
can be used in both positive and
negative applications.
Applications: Venting systems for chemical
fumes; dust collection;
exhausting gases; air
movement.
Standard Colors: Blue
Sizes: 2" I.D. through 18" I.D.
Standard Length: 25 ft. (other lengths up to 50 ft.
available upon request)
Temp. Range: -20°F to +180°F
Features: Excellent flexibility, good
abrasion resistance, good
chemical resistance, good
weathering characteristics.
Applications: Fume removal, ventilation, dust
collection, light material
handling internal cooling and
venting of computers.
Footnote: All pressure and vacuum data based on 72°F temperature.
Footnote: All pressure and vacuum data based on 72°F temperature.
Ultraflex TPC – Type TPC consists of a thermoplastic polyvinyl
chloride (PVC) material reinforced with a spring steel wire helix. It is
an excellent economical choice for industrial applications that require
fume removal, ventilation, dust collection, etc.
Type TPR
Inside Diameter (inches) 2 4 6 8 10
Weight (lbs./ft.) .22 .75 .94 1.62 1.86
Inside Bend Radius 1/2 of I.D.
Burst (psig) 50 32 27 25 22
Working Pressure (psig) 17 11 9 8 7
Compressibility 65%
Temperature Range -60°F to +275°F, +300°F Intermittent
Max. Negative Pressure (in. hg.) 24 24 9 8 6
Type TPC
Inside Diameter (inches) 2 4 6 8 10
Weight (lbs./ft.) .17 .40 .59 .85 1.03
Inside Bend Radius 1/2 of I.D.
Burst (psig) 27 18 17 15 10
Working Pressure (psig) 9 6 5.5 5 3
Compressibility 75%
Temperature Range -20°F to +180°F
Max. Negative Pressure (in. hg.) 20 14 8 6 5
Ultraflex®
The Ultraflex ducting line delivers high performance service to a wide
range of applications. The variety of thermoplastic materials makes
this line exceptionally versatile. Flexibility and compressibility also
make it ideal for many difficult, hard to handle applications. Its
toughness, weatherability and resistance to chemicals and abrasion
allow it to take on the most demanding jobs.
Ultraflex TPR – Type TPR features a helical wire reinforced
thermoplastic rubber suitable for a wide variety of air
handling, fume control, and dust collection applications. It
offers good abrasion resistance, superior chemical resistance,
excellent ozone and weathering resistance, as well as good resistance
to flex fatigue. For additional wear resistance, an orange vinyl wear strip on
the O.D. is also available.
