Page 24 - L table

Ultra-Lok® Tie C
Maximum Minimum
Diameter Loop Tensile Package Package Application
Part No. Material* Width Length Thickness Single Wrap Strength (Lbs) Quantity Weight Tools
In mm In mm In mm In mm Lbs Kg
AU2029 201 SS 1/4 6.4 8 203 0.015 0.38 1.5 38 400 100/bag 1.0 0.5
AU2039 201 SS 1/4 6.4 10 254 0.015 0.38 2.5 63 400 100/bag 1.2 0.6
AU2049 201 SS 1/4 6.4 12 305 0.015 0.38 3.0 76 400 100/bag 1.4 0.7
AU2059 201 SS 1/4 6.4 14 356 0.015 0.38 3.8 96 400 100/bag 1.6 0.8 A94079
AU2069 201 SS 1/4 6.4 16 406 0.015 0.38 4.5 114 400 100/bag 1.9 0.9 IT3000
AU2079 201 SS 1/4 6.4 19 483 0.015 0.38 5.4 137 400 100/bag 2.2 1.0
AU2089 201 SS 1/4 6.4 24 610 0.015 0.38 7.0 177 400 100/bag 2.7 1.3
AU2099 201 SS 1/4 6.4 29 737 0.015 0.38 8.0 215 400 100/bag 3.3 1.5
AU2159 201 SS 1/4 6.4 35 889 0.015 0.38 10.5 266 400 100/bag 3.9 1.8
CE Marked
A94079 Ultra-Lok® Tool
Adjustable tension, forms
lock, cuts off tail.
Ultra-Lok® Tie
K50289 Ball-Lok Tool
Adjustable tension, forms
lock, cuts off tail.
Ball-Lok Tie
Maximum Minimum
Base Material Diameter Loop Tensile Package Package Application
Part No. Material* Width Length Thickness Single Wrap Strength (Lbs) Quantity Weight Tools
Uncoated Coated In mm In mm In mm In mm Lbs Kg
KE1128 - 304 SS 0.180 4.6 7.9 201 0.010 0.25 2.0 50 200 100/bag 0.6 0.3
KE1138 - 304 SS 0.180 4.6 10.2 259 0.010 0.25 2.7 69 200 100/bag 0.7 0.4
KE1148 - 304 SS 0.180 4.6 14.2 360 0.010 0.25 4.0 102 200 100/bag 0.9 0.5
KE1158 - 304 SS 0.180 4.6 20.4 520 0.010 0.25 6.0 152 200 100/bag 1.3 0.6
KE1168 - 304 SS 0.180 4.6 26.8 679 0.010 0.25 8.0 203 200 100/bag 1.8 0.8
KE1178 - 304 SS 0.180 4.6 33.0 838 0.010 0.25 10.0 254 200 100/bag 2.1 1.0
KE1188 - 304 SS 0.180 4.6 42.0 1067 0.010 0.25 12.0 305 200 100/bag 2.4 1.1
KE0128 - 316 SS 0.180 4.6 7.9 201 0.010 0.25 2.0 50 200 100/bag 0.6 0.3
KE0138 - 316 SS 0.180 4.6 10.2 259 0.010 0.25 2.7 69 200 100/bag 0.7 0.4
KE0148 - 316 SS 0.180 4.6 14.2 360 0.010 0.25 4.0 102 200 100/bag 0.9 0.5
KE0158 - 316 SS 0.180 4.6 20.4 520 0.010 0.25 6.0 152 200 100/bag 1.3 0.6
KE0168 - 316 SS 0.180 4.6 26.8 679 0.010 0.25 8.0 203 200 100/bag 1.8 0.8
KE0178 - 316 SS 0.180 4.6 33.0 838 0.010 0.25 10.0 254 200 100/bag 2.1 1.0
KE0188 - 316 SS 0.180 4.6 42.0 1067 0.010 0.25 12.0 305 200 100/bag 2.4 1.1
KE1328 - 304 SS 0.310 7.9 7.9 201 0.010 0.25 2.0 50 300 100/bag 1.0 0.5
KE1338 - 304 SS 0.310 7.9 10.2 259 0.010 0.25 2.7 69 300 100/bag 1.3 0.6
KE1348 - 304 SS 0.310 7.9 14.2 360 0.010 0.25 4.0 102 300 100/bag 1.7 0.8
KE1358 - 304 SS 0.310 7.9 20.4 520 0.010 0.25 6.0 152 300 100/bag 2.2 1.1
KE1368 - 304 SS 0.310 7.9 26.8 679 0.010 0.25 8.0 203 300 100/bag 2.9 1.3
KE1378 - 304 SS 0.310 7.9 33.0 838 0.010 0.25 10.0 254 300 100/bag 3.5 1.6
KE1388 - 304 SS 0.310 7.9 42.0 1067 0.010 0.25 12.0 305 300 100/bag 4.6 2.1
KE0328 - 316 SS 0.310 7.9 7.9 201 0.010 0.25 2.0 50 300 100/bag 1.0 0.5
KE0338 - 316 SS 0.310 7.9 10.2 259 0.010 0.25 2.7 69 300 100/bag 1.3 0.6
KE0348 - 316 SS 0.310 7.9 14.2 360 0.010 0.25 4.0 102 300 100/bag 1.7 0.8
KE0358 - 316 SS 0.310 7.9 20.4 520 0.010 0.25 6.0 152 300 100/bag 2.2 1.1
KE0368 - 316 SS 0.310 7.9 26.8 679 0.010 0.25 8.0 203 300 100/bag 2.9 1.3
KE0378 - 316 SS 0.310 7.9 33.0 838 0.010 0.25 10.0 254 300 100/bag 3.5 1.6
KE0388 - 316 SS 0.310 7.9 42.0 1067 0.010 0.25 12.0 305 300 100/bag 4.6 2.1
- KE0828 316 SS 0.310 7.9 7.9 201 0.010 0.25 2.0 50 300 100/bag 1.2 0.6
- KE0848 316 SS 0.310 7.9 14.2 360 0.010 0.25 4.0 102 300 100/bag 1.8 0.9
- KE0858 316 SS 0.310 7.9 20.4 520 0.010 0.25 6.0 152 300 100/bag 2.5 1.2
K50289
or by hand
CE Marked, DNV Approved, Coast Guard Approved
24 303-320-4555
Multi-Lok Tie
Maximum Minimum
Thickness Diameter Loop Tensile Package Package Application
Part No. Material* Width Length Uncoated Coated Single Wrap Strength Quantity Weight Tools
Uncoated Coated In mm In mm In mm In mm In mm (Lbs) Lbs Kg
AE6019 AE6119 316 SS 0.270 6.9 6.0 150 0.011 0.28 0.018 0.46 1.3 33 250 100/bag 0.7 0.3
AE6029 AE6129 316 SS 0.270 6.9 9.0 225 0.011 0.28 0.018 0.46 2.2 57 250 100/bag 0.9 0.5
AE6039 AE6139 316 SS 0.270 6.9 12.0 300 0.011 0.28 0.018 0.46 3.2 81 250 100/bag 1.3 0.6
AE6049 AE6149 316 SS 0.270 6.9 18.0 450 0.011 0.28 0.018 0.46 5.1 129 250 100/bag 1.8 0.8 AE2009
AE6059 AE6159 316 SS 0.270 6.9 24.0 610 0.011 0.28 0.018 0.46 7.1 180 250 100/bag 2.6 1.2 AE2018
AE7019 AE7119 316 SS 0.470 11.9 6.0 150 0.011 0.28 0.018 0.46 1.3 33 400 100/bag 1.1 0.5 M50389
AE7029 AE7129 316 SS 0.470 11.9 9.0 225 0.011 0.28 0.018 0.46 2.2 57 400 100/bag 1.7 0.8 or by hand
AE7039 AE7139 316 SS 0.470 11.9 12.0 300 0.011 0.28 0.018 0.46 3.2 81 400 100/bag 2.2 1.0
AE7049 AE7149 316 SS 0.470 11.9 18.0 450 0.011 0.28 0.018 0.46 5.1 129 400 100/bag 3.0 1.4
AE7059 AE7159 316 SS 0.470 11.9 24.0 610 0.011 0.28 0.018 0.46 7.1 180 400 100/bag 4.3 2.0
Multi-Lok Ties
AE2009 Cable Tie
Tensioner
M50389 Multi-Lok
Hand Tool
Adjustable tension,
forms lock, cuts off tail.
UL listed, CE Marked, DNV Approved
Tie
lti-Lok Tie
*BAND-IT reserves the right to substitute material with equal or better corrosion resistance and/or mechanical specifications.
Ball-Lok Ties
Printed on recycled paper
