TUBE CONVEYOR AND BUNK
FEEDER SYSTEMS
PVC Herringbone for 30 degree inclines
(USDA & FDA)
PVC Nylock ® Chevon™
PVC Nylock ® Cleated Incline
PVC Nylock ® low-temp
Cotton processing equipment
Gin flashing material
PACKAGE HANDLING
BELTS FOR INCLINES(1)
Griptop ® — 35 degree inclines
Gripper ™ — Light impression for up to
20 degree inclines
PVC Chevron™ and Cleated Incline —
Molded pattern helps move loose material
on moderate inclines to 35 degrees
depending on product
PVC Nylock ® for up to 18 degree inclines
at normal temperatures; up to 15 degree
inclines at low temperatures
PVC Herringbone for up to 30 degree inclines
Griptite™ for up to 20 degree inclines
BELTS FOR STEEP INCLINES
OF 45 DEGREES
Diamond Incline
V-Cleat
Ribflex
BELTS FOR HORIZONTAL SERVICE
Caripack ®
Slide-A-Pack ®
Sliptop®
Sheeting Belt
Hot Stock & Water
PVC Nylock ®
(1) Smooth surface belts are generally satisfactory for
inclines up to 15 degrees.
LIGHT INDUSTRIAL & AUTOMATION
BELTS WHEN OIL IS PRESENT
Saniwhite ® & Sani-Brite™ nitrile rubber
(Polyester, PNT, SCP)
Griptop® (Nitrile & Carboxylated Nitrile) —
for 35 degree inclines
Sliptop®
Teflon
BELTS FOR OIL-FREE SERVICE
PVC Nylock ® & Korowhite™
Hot Stock & Water
Caripack ®
Slide-A-Pack ®
Potato (Utility)
SPECIAL APPLICATION BELTS
Big Red™ — Hot or Cold Tacky Material
Plywood processing — Tray
Lumber service — Lumber
Rubber processing — Hot Stock & Water
Cotton gins — Flashing material
