Page 35 - GOODYEAR RUBBER PRODUCTS INC 1-866-711-4673 Snaptite Municipal Fire Hose Catalog

High Temp
Performance Features:
Cotton inherently has a higher heat resistance than synthetics and
when combined with the clear mildew treatment our 2H hose has been
designed to handle many of the high ambient temperature conditions
found in today’s industrial applications. 2H utilizes an EPDM rubber
liner that resists ozone and many acids, alkalis and chemicals. This
hose has a maximum operating pressure of 225 psi (1550 kPa).
SERVICE PROOF WEIGHT BOWL
SIZE BURST
TEST TEST SIZE
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: 2H10X50WM10N = 2H Hose, 1” ID by 50’ Length, White/Mildew, 1” Aluminum NH/NST
Threaded Coupling
How to Order
2H 10X50 WM 10 N
2H 10 = 1” 50 = 50’ WM = White 10 = 1” N = NH Blank=
100 = 100’ (Mildew I = IPT Aluminum
Treated)
High Temp
Performance Features:
National 3H high temperature hose is the ultimate for high heat
protection as its outer jacket is made of DuPont’s Kevlar/Nomex™
fiber. 3H exceeds all known standards for heat resistance and is
so durable, it’s virtually indestructible.
No other jacketed hose can prevent hose failure due to flame
exposure like 3H. It even resists ozone and mildew and requires
no drying. Superior cut and abrasion resistance enhances its
outstanding durability - Certainly the perfect hose for industrial
firefighting. 3H has a maximum operating pressure of 225 psi
(1550 kPa).
SERVICE PROOF WEIGHT BOWL
SIZE BURST
TEST TEST SIZE
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: 3H17X50W15N = 3H Hose, 1-3/4” ID by 50’ Length, White, 1-1/2” Aluminum NH/NST
Threaded Coupling
How to Order
3H 17X50 W 15 N
3H 10 = 1” 50 = 50’ W = White 10 = 1” N = NH Blank=
17 = 1-3/4” 100 = 100’ (Uncoated) 15 = 1-1/2” I = IPT Aluminum
BR=Brass Rocker
Lug (1-3/4” only)
Construction:
Kevlar/Nomex™Jacket
EPDM Rubber Inner Liner
with Rubber Backing
Temperature Range:
Intermittent -40° to 300°F
(-40° to 150°C)
Continual 225°F (110°C)
Coupling:
Aluminum or Brass NH/NST
or IPT Threaded
Hose Colors:
Cotton Single Jacket Hose
Kevlar/Nomex™ Single Jacket Hose
EPDM Rubber Liner
Kevlar/Nomex™ Jacket
Rubber Backing
Construction:
Cotton Single Jacket
EPDM Rubber Inner Liner
with Rubber Backing
Coating:
Mildew Treatment
Temperature Range:
-40° to 225°F Continual
(-40° to 110°C)
Coupling:
Aluminum NH/NST or
IPT Threaded
Hose Colors:
(for 50’ coupled)
Kevlar/Nomex is a registered Trademark of the DuPont Company
(for 50’ coupled)
Neoprene Rubber Liner
Cotton Single Jacket
Rubber Backing
- Type 2H
- Type 3H
I -9
PSI (kPa) PSI (kPa) PSI (kPa) LBS KG IN
1” 250 (1725) 500 (3450) 750 (5170) 9 4.1 1-5/32
Operating Pressure not to Exceed 90% of Service Test Pressure
Operating Pressure not to Exceed 90% of Service Test Pressure
PSI (kPa) PSI (kPa) PSI (kPa) LBS KG IN
1” 250 (1725) 500 (3450) 750 (5170) 9 4.1 1-5/32
1-3/4” 250 (1725) 500 (3540) 750 (5170) 13 5.9 1-15/16
