Parker Industrial Hose Customer Service
866 810 HOSE (4673) 800 242 HOSE (4673)
Strongsville, OH
South Gate, CA
Eastern USA
Western USA
www.safehose.com
e-mail: indhose@parker.com
PVC
NEXSYN
H61 EPDM/ TPV Hose
FDA, ANSI /NSF 51 and ANSI /NSF 61 Compliant
Tube Compound, RoHS Compliant
Series 715
Series 715 hose is extruded to close tolerances using specially designed thermoplastic
vulcanizate (TPV) materials that perform like EPDM rubber. Te mechanical and
recovery properties are comparable to most vulcanized elastomers and superior to most
thermoplastic elastomers. Series 715 is 25–35% lighter than PVC and rubber hose of the
same dimensions, handles higher operating temperatures than PVC hose and maintains
fexibility at cold temperatures. Tis highly durable hose is resistant to fex fatigue, ozone
and ultraviolet light, and has excellent resistance to a wide range of mild acids, alkalis,
chemicals and deionized water. Te opaque cover inhibits algae growth.
Tube:
Natural EPDM/TPV
Reinforcement:
Multiple textile plies
Cover:
Gray EPDM/TPV; smooth fnish
Temp. Range:
-75°F to +180°F (-60°C to +82°C)
Working pressures are at +68°F (+20°C). Higher temperatures reduce the
available working pressure. See temperature/pressure chart on page 445.
Brand Method:
Black ink
Brand Example:
NEXSYN H61 BY PARKER NEXGEN
®
(P/N) (ID) X (OD) ANSI/NSF-61
COMPLIANT TUBE MATERIAL MAX 200 PSI WP AT 20C DATE CODE
Industry Standards:
• Tube material NSF 51 and NSF 61 listed
• All ingredients in the tube compound are listed in the US FDA CFR,
Title 21
• RoHS Compliant
• EU Directive 2003/11/EC Compliant
Applications:
• Beverages, potable water; mild acids, alkalis and chemicals
• Bottled water plants, marine drinking water lines, temporary municipal
water connections; dishwasher supply lines
Packaging:
Coils
Part
Number
ID
(in)
ID
(mm)
Reinf
Plies
OD
(in)
OD
(mm)
Approx
Wt
(lbs/ft)
Approx
Wt
(kg/ft)
Max
Rec WP
(psi)
@ 68°F
Max
Rec WP
(bar)
@ 20°C
Std Pack
Qty
(ft)
Stock
Status
**
(USA)
715-06007300
3/8
9.5
2
0.625 15.9 0.09 0.04 200 13.8 300
N
715-08007300
1/2
12.7
2
0.750 19.1 0.11 0.05 200 13.8 300
N
715-10007300
5/8
15.9
2
0.875 22.2 0.13 0.06 200 13.8 300
N
**
Stock:
“Y” indicates stocked item; “N” indicates non-stocked item. Stock status subject to change. Contact Parker Customer Service.
!
!
WARNINGS!
Couplings attached with bands or clamps may reduce the working pressure of the hose assembly to less than the maximum rated working
pressure of the hose. Refer to the NAHAD Industrial Hose Assembly Guidelines.
Working pressures are at +68°F (+20°C). Higher temperatures reduce the available working pressure. See temperature/pressure chart on
page 445.
!
!
