20
OETIKER
MINI Worm Drive Clamps
Product Group 180
www.oetiker.com Rights to make technical changes in the interests of further development reserved 08901456
MINI R+S Worm Drive Clamps
MINI R+S Worm Drive Clamps with embossed perforations are resistant
to rust and acids, and based on DIN 3017. Their non-magnetic properties
and minimal space requirements make them especially suitable for
securing magnetic sensors, particularly on pneumatic cylinders.
Material
– 180 W4 Strip and fastener:
Stainless Steel, Material no. 1.4301 / UNS S30400
Screw:
Stainless Steel, Material no. 1.4305 / UNS S30300
Size range Width x Thickness
7.0 - 219.0 mm 5.0 x 0.4 mm
Installation
Installation instructions available on request.
The OETIKER MINI R+S Worm Drive Clamp, with wing integrated into
the fastener, is especially suitable for laboratories, hobbies and other
applications that demand simple, fast assembly and dismantling.
The torsionally stiff wing with special embossed pattern ensures a
good grip.
Features
• Embossed clamp strip – not perforated
• Compact design – minimal space requirement
• Reusable
• Cylindrical screw head with screwdriver slot
• Fast, simple and safe installation
• Type R+S is resistant to rust and acids and non-magnetic
• Alternative with wing screw – a tool integrated in the clamp
MINI R Worm Drive Clamps
MINI R Worm Drive Clamps with embossed perforations are used, for
example, in automobile manufacturing to connect fuel lines and,
because of their open design, are easy to install on pre-assembled
hoses.
Material
– 180 W2 Strip:
Rust-resistant Chromium Steel, Material no. 1.4016 / UNS S43000
Screw and body:
Steel, zinc-plated, chromated blue
Size range Width x Thickness
6.0 - 19.0 mm 5.0 x 0.4 mm
Installation
Installation instructions available on request.
®
For detailed information, please request the Technical Data Sheet for this OETIKER
product group. Send your sample parts and all relevant information for your specific
application to OETIKER, and you will receive our recommendation for product type,
diameter, and method of installation.
Typ R+S
with integrated wing, preassembled
Typ R
Can be supplied open or closed
