60 DurometerWhite Neoprene Extrusion
White neoprene square extrusion. 60 durometer. Resistant to oils and solvents.
Will not darken. Cleans easily with soap and water. Excellent resistance to
weathering. Tensile strength - 800 PSI. Elongation - 500%.
STYLE 0295W Dimensions (inches) Part Number
1/2 x 1/2 0295W500
5/8 x 5/8 0295W625
60 Durometer Silicone Extrusion
Silicone square and rectangular extrusion. 60 durometer. Recommended for
applications requiring a wide temperature range and good dry heat resistance.
Tensile strength - 1100 PSI. Elongation - 250%. Compression set - 23%.
Service temperature range: -75°F to 400°F. Gray color.
STYLE 0294
60 Durometer EPR Extrusion
EPR square and rectangular extrusion. 60 durometer. Used where temperature
and weather resistance are factors in the application. Excellent resistance to
ozone, oxygen, weather, heat, and many chemicals. Tensile strength - 1700 PSI. Elongation - 400%. Temperature
range: -40°F to 275°F, intermittent to 300°F.
STYLE 0292
70 Durometer Fluoroelastomer Extrusion
70 durometer Viton® extrusion in square and rectangular profiles. A-Type Viton®.
Temperatures up to 500°F for 1000 hours, 400°F for 365+ days. Good chemical
resistance. Tensile strength - 2000 PSI. Elongation 225%. Compression set - 8%.
STYLE 0293
Dimensions (inches) Part Number
1/2 x 1/2 0292500
5/8 x 5/8 0292625
1/2 x 3/4 0292500x750
Dimensions (inches) Part Number
5/8 x 7/8 0293625x875
Dimensions (inches) Part Number
1/2 x 1/2 0294500
5/8 x 5/8 0294625
5/8 x 7/8 0294625x875
Extrusions
Closed Cell Neoprene Sponge Cord
Closed cell neoprene sponge cord. Black color. Compression deflection - 5.0 to
9.0 PSI. Compression set - 15% to 25%. Water absorption by weight - 5%
maximum. Density (P.C.F.) - 192/400. Temperature resistance: -60°F (low),
150°F (high continuous), 200°F (high intermittent). Used for sealing, gasketing,
insulating, floatation, vibration dampening, and cushioning.
STYLE 0287 Diameter (inches) Part Number
1/8 0287125
3/16 0287187
1/4 0287250
5/16 0287312
3/8 0287375
1/2 0287500
5/8 0287625
3/4 0287750
1 02871
