Extender 350 Silicon Hump hose single arch
is a softwall
flexible connector designed to provide maximum service life in
pleasure and commercial marine applications where vibration
and minor misalignment is an issue.
Connector exceeds SAE J2006.
Cover:
Metallic Blue
Construction:
4 Ply polyester to SAE J2006 Standards
Temperature range:
-65º to +350ºF (-54º to +177ºC)
Warranty:
10 years
Hose ID
Cuff OD
Part No
Inches MM Inches MM Ply OAL”
202V1H-02000-00 2”
50.8 3.37 60.28 4 6
202V1H-02120-00 2 1/2” 57.25 2.82 71.53 4 6
202V1H-03000-00 3”
76.2 3.37 85.65 4 6
202V1H-03120-00 3 1/2” 88.9 3.82 96.93 4 6
202V1H-04000-00 4”
101.6 4.37 111.03 4 6
202V1H-05000-00 5”
127
5.37 135.45 4 6
202V1H-06000-00 6”
152.4 6.37 161.75 4 8
202V1H-08000-00 8”
203.2 8.37 212.6 6 8
202V1H-10000-00 10”
254
10.37 260.45 6 12
Hose ID
Cuff OD
Part No.
ID” MM OD”
MM OAL”
202V2H-06000-00 6”
152.4 6.37 161.75 14
202V2H-08000-00 8”
203.2 8.37 212.6 14
202V2H-10000-00 10’
254
10.37 263.45 14
202V2H-12000-00 12” 304.8 12.37 314.2 14
202V2H-14000-00 14” 355.6 12.37 365
14
202V2H-16000-00 16” 406.4 16.37 415.8 14
202V2H-18000-00 18” 457.2 18.37 457.2 18
Extender 350 Silicon Hump Hose
double arch
is a softwall
flexible connector designed to provide maximum service life in
pleasure and commercial marine applications where vibration and
minor misalignment is an issue. Connector exceeds SAE J2006.
Cover:
Metallic Blue
Construction
:4 Ply polyester construction to SAE J2006 standards
Temperature range
: -65º to +350ºF (-54º to +177ºC)
Warranty:
10 years
Part No.
Inches MM Inches MM WP
psi
131V-00140-00 1/4”
6.35
.46”
11.68 105
131V-00380-00 3/8”
9.53
.64”
16.13 105
131V-00120-00 1/2”
12.7
.76”
19.3
112
131V-00580-00 5/8”
15.88 .93”
23.5
75
131V-00340-00 3/4”
19.05 1.07”
27.18 68
131V-01000-00 1”
25.4
1.38”
35.01 50
Extender 350 Silicon Heater Hose 131V
is a softwall
flexible connector designed to provide maximum service
life in pleasure and commercial marine applications for
the transfer of water or antifreeze. Extender 350 meets or
exceeds SAE 20 R3 Class 4.1.4.
Cover:
Royal Blue
Construction:
Polyester reinforcement
Temperature range:
-65º to +350ºF (-54º to +177ºC)
Warranty:
10 years
Extender 350
Heater Hose 131V
Extender 500 Hump Hose
Single Arch (aramid fabric)
Extender 350
Hump Hose
Double Arch
Extender 350 Hump Hose Single Arch
Extender 500 202X1H (500ºF) change V in part # to X—all other data the same
Extender 500 Hump
Hose
Double Arch
(aramid fabric)
Extender 500 202X2H (500ºF) change V in part no. to X—all other data the same
Actual burst pressure is minimum 4 times working pressure
mp •
Elbows
90° 45° •
Specials
reducers heater hose
