MARINE HOSE
APPLICATION
CHARTS
500
°
F Silicone
SYSTEMS
Novaflex flexible, high-temperature
resistant silicone rubber exhaust hoses
and connectors meet SAE J2006,
ABYC, NMMA, and provide superior
vibration and noise abatement.
SERIES
252V
350ºF HARDWALL
EXHAUST HOSE
Extender 350
°
F Silicon Wet Exhaust hose
is a hardwall highly flexible hose designed
to provide maximum service life in pleasure
and commercial marine exhaust applications.
Hose exceeds SAE J2006
Cover: Metallic Blue
Construction: 2 ply polyester to SAE J2006 standards
Temperature range: -65º to +350ºF (-54º to +177ºC)
Working Pressure: 25% of Burst Pressure
Warranty: 10 years
SIZE:
3
/
4
” to 10”
HUMP HOSE
SINGLE/DOUBLE ARCH
EXTENDER 350
°
F
Extender 350F Silicon Hump Hose single
or double arch is a soft wall highly flexible
connector designed to provide maximum service
life in pleasure and commercial marine exhaust applications
where vibration and minor misalignment is an issue.
Hose exceeds SAE J2006
Cover: Metallic Blue
Construction: 2 ply polyester to SAE J2006 standards
Temperature range: -65 to +350F (-54 to + 177C)
Warranty: 10 years
SIZE: 2” to 12”
90
°
ELBOW
CONNECTOR
EXTENDER 350
°
F
Extender 350
°
F Silicon 90
°
elbow connector is
a softwall flexible connector designed to provide
maximum service life in pleasure and commercial
marine applications where vibration and minor
misalignment is an issue. Connector exceeds
SAE J2006.
Cover: Metallic Blue
Construction: 4ply polyester construction to SAE J2006 standards
Temperature range: -65º to +350ºF (-54º to +177ºC)
Warranty: 10 years
SIZE: 2” to 4
1
/
2
”
SERIES
202V
SOFTWALL EXHAUST HOSE
Extender 202V 350
°
F Silicon Wet Exhaust
hose is a softwall flexible hose designed
to provide maximum service life in pleasure
and commercial marine exhaust applications.
Hose exceeds SAE J2006.
Cover: Metallic Blue
Construction:4 ply polyester to SAE J2006 standards
Temperature range: -65º to +350ºF (-54º to +177ºC)
Working Pressure: 25% of burst pressure
Warranty: 10 years
SIZE: 1” to 18”
45
°
ELBOW
CONNECTOR
EXTENDER 350
°
F
Extender 350
°
F Silicon 45
°
elbow connector is
a softwall flexible connector designed to provide
maximum service life in pleasure and commercial
marine applications where vibration and minor
misalignment is an issue. Connector exceeds
SAE J2006.
Cover: Metallic Blue
Construction: 4ply polyester construction to SAE J2006 standards
Temperature range: -65º to +350ºF (-54º to +177ºC)
Warranty: 10 years
SIZE: 2” to 4
1
/
2
”
HUMP HOSE
SINGLE/DOUBLE ARCH
EXTENDER 500
°
F
Extender 500
°
F Silicon Hump Hose single
or double arch is a soft wall highly flexible
connector designed to provide maximum service
life in pleasure and commercial marine exhaust applications
where vibration and minor misalignment is an issue.
Hose exceeds SAE J2006
Cover: Orange
Construction:2 ply Aramid to SAE J2006 standards
Temperature range: -65º to +500ºF (-54º to +260ºC)
Warranty: 10 years
SIZE: 2” to 12”
90
°
ELBOW
CONNECTOR
EXTENDER 500
°
F
Extender 500
°
F Silicon 90
°
elbow connector is
a softwall flexible connector designed to provide
maximum service life in pleasure and commercial
marine applications where vibration and minor
misalignment is an issue. Connector exceeds
SAE J2006.
Cover: Orange
Construction: 4 ply Aramid construction to SAE J2006 standards
Temperature range: -65º to +500ºF (-54º to +260ºC)
Warranty: 10 years
SIZE: 2” to 4
1
/
2
”
SERIES
202X
SOFTWALL EXHAUST HOSE
Extender 202X 500
°
F Silicon Wet Exhaust
hose is a softwall flexible hose designed
to provide maximum service life in pleasure
and commercial marine exhaust applications.
Hose exceeds SAE J2006.
Cover: Orange
Construction:4 ply Aramid to SAE J2006 standards
Temperature range: -65º to +500ºF (-54º to +260ºC)
Working Pressure: 25% of burst pressure
Warranty: 10 years
SIZE: 1” to 18”
45
°
ELBOW
CONNECTOR
EXTENDER 500
°
F
Extender 500
°
F Silicon 45
°
elbow connector is
a softwall flexible connector designed to provide
maximum service life in pleasure and commercial
marine applications where vibration and minor
misalignment is an issue. Connector exceeds
SAE J2006.
Cover: Orange
Construction: 4 ply Aramid construction to SAE J2006 standards
Temperature range: -65º to +500ºF (-54º to +260ºC)
Warranty: 10 years
SIZE: 2” to 4
1
/
2
”
HEATER HOSE
SERIES
131V
EXTENDER 350
°
F
Extender 350
°
F Silicon Heater Hose 131V
is a softwall flexible hose designed to
provide maximum service life in pleasure
and commercial marine applications for the
transfer of water or antifreeze. Extender 350
meets or exceeds SAE 20 R3 Class 4.1.4.
Cover: Metallic Blue
Construction: Polyester reinforcement
Temperature range: -65º to +350ºF (-54º to +177ºC)
Warranty: 10 years
SIZE:
1
/
4
”,
3
/
8
”,
1
/
2
”,
5
/
8
”,
3
/
4
”, 1”, 1
1
/
4
”,
350
°
F Silicone
SYSTEMS
SERIES
252X
500ºF HARDWALL
EXHAUST HOSE
Extender 500
°
F Silicon Wet Exhaust hose
is a hardwall highly flexible hose designed
to provide maximum service life in pleasure
and commercial marine exhaust applications.
Hose exceeds SAE J2006
Cover: Orange
Construction:2 ply Aramid to SAE J2006 standards
Temperature range: -65º to +500ºF (-54º to +260ºC)
Working Pressure: 25% of Burst Pressure
Warranty: 10 years
SIZE:
3
/
4
” to 10”
