MARINE HOSE
SERIES 128
SPLIT CONDUIT
HOSE
Flame Retardant
Cable/Wire Harness
Cover. Split for easy
access to route wires.
V2 Rated UL 94A
Available in black or white.
SIZES: 1/4”, 3/8”, 1/2”, 5/8”, 3/4”,
1”, 1 1/4”, 1 1/2”, 2”
SERIES 186
OUTBOARD MOTOR
BRACKET HOSE
Cable conduit designed
to conceal hose or cable
of outboard motor.
Available in black or grey.
SIZES: 1 1/2”, 2”
SERIES 400/402
VENTILATION
DUCTING
Flame resistant PVC
ducting designed for
venting bilge gases.
Ozone and sunlight resistant.
Available in white (402).
SIZES: 3”, 4”
Conduit/Ventilation SYSTEMS
SERIES 200/260
SOFTWALL
EXHAUST HOSE
Designed for a wide range
of water transfer and discharge
applications as well as the tough
demands of wet exhaust. The softwall (non-wire)
construction is designed for straight routings. An
excellent choice for bilge, toilet, scupper and water
discharge applications that are straight. Meets
SAEJ2006 R1 for marine exhaust hose.
Available in heavy duty version (260).
SIZE: 3/4” to 18”
SERIES 250/210
HARDWALL
EXHAUST HOSE
Designed for a wide range
of demanding engine
applications from water intake
and engine coolant to marine wet
exhaust. It’s wire helix construction provides excellent
flexibility and bend radius. Also an excellent choice for
bilge discharge, toilet and holding tank connections,
water discharge and scupper lines. Meets SAEJ2006 R2
for marine exhaust hose.
Available in heavy duty version (210).
SIZE: 1/2” to 8”
SERIES 252
CORRUGATED
EXHAUST HOSE
Designed to meet the tough
demands of wet exhaust.
The hose is constructed to resist
panting, vibration and wall collapse.
Helical wire construction (hardwall) allows the hose
to accept bending without collapsing. The minimum
designed bend radius of the hose is calculated by
multiplying the inside diameter of the hose by four.
The corrugated design is more flexible than the
250 Series hose making it a better choice for tight
bends and retro fit applications.
SIZE: 1” to 12”
Exhaust SYSTEMS
APPLICATION
CHARTS
SERIES 373
CORRUGATED
FUEL FILL HOSE
Designed to meet fuel hose
specifications of SAE J1527 and
ISO 7840. The helical wire construction
provides flexibility and collapse resistance for applications
requiring a tight bend radius. This hose meets all the
requirements of the USCG, NMMA, ABYC and is certified by
IMCI for use in the European community. This A-2 hose is
designed for fill applications where the fuel is not normally
continuously in the hose. The flame resistant cover is designed
for enclosed engine compartment applications.
SIZE: 11/2”, 17/8”, 2”, 3”
SERIES 360-03
FUEL FEED AND
VENT HOSE (ALL RUBBER)
Designed to meet fuel hose specifications
of SAE J1527 and ISO 7840. The all rubber
construction offers greater flexibility and
compression for ease of coupling installation.
Formulated to handle gasoline, diesel and alcohol blended
fuels. This hose meets all requirements of the USCG, NMMA,
ABYC and is certified by IMCI for use in the European
community. The 360-03 series is an A-1 hose that can be
used in a feed or vent application. The flame resistant cover
is designed for enclosed engine compartment applications.
SIZE: 1/4”, 5/16”, 3/8”, 1/2”, 5/8”
SERIES 360-00
FUEL FEED AND
VENT HOSE (BARRIER)
Designed to meet fuel hose
specifications of SAE J1527 and
ISO 7840. The barrier construction
provides the lowest permeation rating available for
any marine fuel hose. Formulated to handle gasoline, diesel and
alcohol blended fuels. This hose meets all the requirements of
the USCG, NMMA, ABYC and is certified by IMCI for use in the
European community. The 360-00 series is an A-1 hose that can
be used in a feed or vent application. The flame resistant cover is
designed for enclosed engine compartment applications
SIZE: 1/4”, 5/16”, 3/8”, 1/2”, 5/8”
Series 375-ULP
ULTRA-LOW PERMEATION
FUEL FILL HOSE
Designed with all the flexibility of
traditional rubber hose for complex
shapes and easy installation. This hose
features; ultra low fuel permeation and
excellent permeation resistance and uses
a wide range of rubber hose clamps and fittings.
It is resistant to oxygenated and sour fuels with superior
heat aging for longer life.
Meets SAE J1527 and ISO 7840 standards
SIZE: 1/2” to 18”
SERIES 375
SMOOTH
FUEL FILL HOSE
Designed to meet fuel hose
specifications of SAE J1527 and
ISO 7840. The helical wire construction
provides flexibility and collapse resistance for applications
requiring a tight bend radius. This hose meets all the
requirements of the USCG, NMMA, ABYC and is certified by
IMCI for use in the European community. This A-2 hose is
designed for fill applications where the fuel is not normally
continuously in the hose. The flame resistant cover is designed
for enclosed engine compartment applications.
SIZE: 1/2” to 8”
SERIES 315
OUTBOARD
FUEL LINE
Very flexible fuel line designed
only for outboard engine applications.
Designed to handle alcohol blended
fuels as well as oil and gasoline mixtures.
Meets SAEJ1527 B2
SIZE: 3/8”
Fuel SYSTEMS
