NO Description
Material
1
Body
C84400
2
Filter
304
3
Gasket
PTFE
4
Cap
C84400
V
ALVES
Part#
Size
A
B
D
Box
Case
940-521
1/4"
2.60
1.89
0.41
10
80
----
940-522
3/8"
2.60
1.89
0.41
10
80
----
940-523
1/2"
2.992
1.811
0.498
10
100
----
940-524
3/4"
3.583
2.205
0.531
10
60
----
940-525
1"
4.252
2.677
0.63
5
40
----
940-526
1-1/4"
4.882
3.15
0.669
4
24
----
940-527
1-1/2"
5.669
3.583
0.709
4
16
----
940-528
2"
6.772
4.37
0.827
2
8
----
940-529
2-1/2"
8.39
5.83
0.93
1
6
----
940-530
3"
9.06
6.69
1.12
1
4
----
REPLACEMENT SCREENS
304 S.S. #20 Mesh
Part #
Size
OAL
940-521S
1/4
1.5
----
940-522S
3/8
1.5
----
940-523S
1/2
1.57
----
940-524S
3/4
1.97
----
940-525S
1
2.44
----
940-526S
1-1/4
2.76
----
940-527S
1-1/2
3.31
----
940-528S
2
4.06
----
940-529S
2-1/2
5.25
----
940-530S
3
5.90
----
CLASS 150 BRONZE Y-PATTERN STRAINER
• Casting bronze body, size 1/2"-3".
• Pressure rating: 300 WOG (water, oil, gas)/PN25
150 WSP (Saturated Stem)
• NPT Threaded ends to ANSI B1.20.1
• Protects regulators, pumps, meters and other
controls from damage due to sediment scale, metal
chips or other foreign materials.
•Screwed cap is threaded & gasketed.
•Tapped drain plug opening in cap.
•304 stainless steel screen #20 mesh.
•Self cleaning.
•Self cleaning can be accomplished by
opening the valve or plug connected to
the blow-off outlet.
Y S
TRAINERS
B
RASS
V
ALVES
A
B D
2
4 3
1
"New dimensions for 1/2 thru 2"
