166
Part# Size DN A B C E
E1 CH1 CH2 Box Case
948-101
1/4
.31 2.28 1.49 3.35 .46 .51 .55 .74 24 96 ----
948-102
3/8
.39 2.37 1.57 3.35 .46 .51 .71 .86 24 96 ----
948-103
1/2
.59 2.28 1.49 3.35 .61 .59 .85 .96 14 56 ----
948-104
3/4
.78 2.87 1.57 3.35 .66 .63 1.10 1.22 12 48 ----
948-105
1
.98 3.42 1.93 5.20 .77 .75 1.36 1.50 6 24 ----
948-106
1-1/4 1.26 3.94 2.36 4.72 .79 .76 1.69 1.89 4 16 ----
948-107
1-1/2 1.57 4.25 3.00 6.34 .81 .76 2.12 2.12 2 8
----
948-108
2 1.97 4.96 2.95 6.34 .84 .76 2.40 2.63 1 4
----
ITALIAN M X F -
*
CLOSE-OUT ONCE STOCK IS GONE
*
V
ALVES
M
ALE
x F
EMALE
B
ALL
V
ALVES
B
RASS
V
ALVES
• Solid chrome plated brass ball
• Suitable for full range of liquids and gases.
• Minimal pressure drop due to large full size ports.
• Bottom loaded, pressure retaining stem.
• Pressure rated at 600psi (42 bars) WOG ( non-shock)
and 150psi (10.34 bars) saturated steam. Virgin TFE
stem packing seal, thrust washer and seats.
• Yellow vinyl insulator on heavy duty plated carbon
steel handles.
• Fast 1/4 turn open or close operation.
• Flow both directions.
• Low operating torque.
• Adjustable stem packing gland.
Gas Approved
• Maximum operating temperature: 248
0
F (120
0
C)
• Minimum operating temperature: -20
0
F (-40
0
C)
• Each valve individually tested.
• Forged Brass - for more strength.
• Threaded ends to ANSI B1.20.1
• Hard chromium plated solid ball
• Bottom entry, blow-out proof stem.
FULL PORT 600WOG FORGED BRASS BALL VALVE
MADE IN CHINA
CSA AGA 3.88 5 PSIG
UL842, UL258, UL125,FM
FM
U L
Part# Size
NPT
A B C D E Box Case
948-170
1/4
1/4 - 18
2.016 1.689 2.756 0.315 0.457 70 140 ----
948-171
3/8
3/8 - 18
2.094 1.732 3.543 0.394 0.457 70 140 ----
948-172
1/2
1/2 - 14
2.343 1.941 3.543 0.583 0.520 50 100 ----
948-173
3/4
3/4 - 14
2.618 2.106 3.780 0.748 0.563 30 60 ----
948-174
1
1 - 11.5
3.000 2.579 4.528 0.945 0.630 20 40 ----
948-175
1-1/4 1-1/4 - 11.5 3.563 2.953 4.528 1.260 0.709 12 24 ----
948-176
1-1/2 1-1/2 - 11.5 3.965 3.346 5.512 1.575 0.717 9 18 ----
948-177
2
2 - 11.5
4.496 3.681 5.512 1.969 0.748 6 12
----
POS Components
Materials
1
Body
C37700
2
End Cap
CS7700
3
Ball Seat
PTFE
4
Ball
CS7700
5
Stem
CS7700
6
Stem Reducing
PTFE
7
Reducing Nut
CS7700
8
Lever Handle
1008
9
Stem Nut
A570 Gr.A
NEW
