LENGTH CONSIDERATIONS
Lateral Offset
Formula:
L = v 20R x T
Lp = v L2 - T2
Note 1: When the offset motion occurs on both sides of the hose centerline, use total travel in
the formula
Note 2: The offset distance “T” for constant fexing should never exceed 25% of the centerline
bend radius
Angular Deflection
Formula:
L = 2S + (0/57.3)R
Vertical Loop with Movement In Two Directions (Combination Loop)
Formula:
L = 4R + 1.57T1 + (T2/2)
